CMF12069.53KOHMS0.1%50PPMTAPE datasheet, PDF

Datasheet> All Categories > Passive components> The resistor> CMF12069.53KOHMS0.1%50PPMTAPE

CMF12069.53KOHMS0.1%50PPMTAPE: DescriptionFixed Resistor, Thin Film, 0.25W, 9530ohm, 300V, 0.1% +/-Tol, -50,50ppm/Cel, 1202,; CategoryPassive components The resistor; File Size224KB，3 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

CMF12069.53KOHMS0.1%50PPMTAPE Overview

Fixed Resistor, Thin Film, 0.25W, 9530ohm, 300V, 0.1% +/-Tol, -50,50ppm/Cel, 1202,

CMF12069.53KOHMS0.1%50PPMTAPE Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	849060640
Reach Compliance Code	compliant
Country Of Origin	Israel
ECCN code	EAR99
YTEOL	10
structure	Rectangular
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	1.6 mm
Package length	3.2 mm
Package shape	RECTANGULAR PACKAGE
Package form	SMT
Package width	0.55 mm
method of packing	Tape
Rated power dissipation(P)	0.25 W
resistance	9530 Ω
Resistor type	FIXED RESISTOR
size code	1202
technology	THIN FILM
Temperature Coefficient	50 ppm/°C
Tolerance	0.1%
Operating Voltage	300 V

CMF12069.53KOHMS0.1%50PPMTAPE Preview

CMF Series

Powertron

FEATURES

•

Resistances from 5.1Ohm to 15MOhms

Power Rating to 0.75 Watts

Resistance Tolerances to ± 0.05%

TCR’s to ± 5 ppm/K

Extreme Low Noise

Precision / Thin Film Resistance Element

TABLE 1—SPECIFICATIONS

Type

Power Rating ( W )

Working Voltage

( VAC )

Resistance Range

(

)

0.1% to 1%

25 / 50

0.1% to 1%

10 / 15 / 25 / 50

0.1% to 1%

5 / 10 / 15 / 25 / 50

0.1% to 1%

5 / 10 / 15 / 25 / 50

0603

0.065

100

0805

0.125

200

1206

0.25

300

2512

0.75

300

Tolerances Available ( % )

Temperature Coefficients Available ( ± ppm/K )

0.1% to 1%

25 / 50

0.1% to 1%

10 / 15 / 25 / 50

0.1% to 1%

5 / 10 / 15 / 25 / 50

0.05% to 1%

5 / 10 / 15 / 25 / 50

0.05% to 1%

5 / 10 / 15 / 25 / 50

0.1% to 1%

5 / 10 / 15 / 25 / 50

0.1% to 1%

25 / 50

0.1% to 1%

10 / 15 / 25 / 50

0.1% to 1%

5 / 10 / 15 / 25 / 50

0.05% to 1%

5 / 10 / 15 / 25 / 50

0.05% to 1%

5 / 10 / 15 / 25 / 50

0.1% to 1%

5 / 10 / 15 / 25 / 50

0.1% to 1%

15 / 25 / 50

5.1W - <10W

0.1% to 1%

25 / 50

0.1% to 1%

10 / 15 / 25 / 50

0.05% to 1%

5 / 10 / 15 / 25 / 50

0.1% to 1%

5 / 10 / 15 / 25 / 50

0.05% to 1%

5 / 10 / 15 / 25 / 50

0.05% to 1%

5 / 10 / 15 / 25 / 50

0.1% to 1%

10 / 15 / 25 / 50

0.1% to 1%

10 / 15 / 25 / 50

10W - <47W

47W - <100W

100W - 332k

>332k - 1M

>1M - 2M

>2M - 5M

>5M - 15M

W @ 70 °C / 0W @ 125 °C

5 / 10 / 15 PPM : +25 °C to +85 °C

1000V Available / contact factory

ORDERING INFORMATION

Part Number - Resistance - Tolerance - TCR - Packaging

CMF 0603 10 kOhms 0.1% 10ppm Tape

( Note: if no TCR is Specified / The highest value will be supplied

Tape available from 100 pieces)

Document No.: 64304

Revision: 05-11-2014

For technical questions,

contact

powertron@vishaypg.com

www.powertron.de

CMF Series

Powertron

TABLE 1—SPECIFICATIONS (continued)

Temperature Range

Climactic Cetegory

Solderability

Max. Soldering Temperature

-55°C to +125°C

55 / 125 / 56

245°C / 3s

260°C / 10s

Long Term Stability

Storage 155°C / 1000h

Storage 125°C / 1000h

Load Life / P=70% / 70°C / 1000h

Humidity / 96%RH / 40°C / 56 days

Max

< 47W

<±0.5%

<±0.25%

<±0.5%

47W - 15 MW

<±0.35%

<±0.15%

<±0.1%

<±0.15%

FIGURE 1—DERATING

Power Derating Curve

120

100

Power ( % )

100

125

150

175

Ambient Temperature (°C)

FIGURE 2—DIMENSIONS

in inches [mm]

Type

CMF 0603

CMF 0805

CMF 1206

CMF 2512

Dimensions

0.063

±0.004

[ 1.6

±0.1

]

0.080

±0.004

[ 2.0

±0.1

]

0.126

±0.008

[ 3.2

±0.2

]

0.248

±0.008

[ 6.3

±0.2

]

0.030

±0.004

[ 0.8

±0.1

]

0.050

±0.004

[ 1.25

±0.1

]

0.063

±0.006

[ 1.6

±0.15

]

0.126

±0.006

[ 3.2

±0.15

]

0.018

±0.004

[ 0.45

±0.1

]

0.022

±0.004

[ 0.55

±0.1

]

0.022

±0.004

[ 0.55

±0.1

]

0.022

±0.008

[ 0.55

±0.2

]

0.012

±0.008

[ 0.3

±0.2

]

0.016

±0.008

[ 0.4

±0.2

]

0.020

±0.008

[ 0.5

±0.2

]

0.020

±0.008

[ 0.5

±0.2

]

www.powertron.de

For technical questions,

contact

powertron@vishaypg.com

Document No.: 64304

Revision: 05-11-2014

Legal Disclaimer Notice

Vishay Precision Group, Inc.

Disclaimer

ALL PRODUCTS, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE.

Vishay Precision Group, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf

(collectively, “VPG”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein or in

any other disclosure relating to any product.

The product specifications do not expand or otherwise modify VPG’s terms and conditions of purchase, including but

not limited to, the warranty expressed therein.

VPG makes no warranty, representation or guarantee other than as set forth in the terms and conditions of purchase.

To the maximum extent permitted by applicable law, VPG disclaims (i) any and all liability arising out of the

application or use of any product, (ii) any and all liability, including without limitation special, consequential or

incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular purpose,

non-infringement and merchantability.

Information provided in datasheets and/or specifications may vary from actual results in different applications and

performance may vary over time. Statements regarding the suitability of products for certain types of applications

are based on VPG’s knowledge of typical requirements that are often placed on VPG products. It is the customer’s

responsibility to validate that a particular product with the properties described in the product specification is suitable for

use in a particular application. You should ensure you have the current version of the relevant information by contacting

VPG prior to performing installation or use of the product, such as on our website at vpgsensors.com.

No license, express, implied, or otherwise, to any intellectual property rights is granted by this document, or by any

conduct of VPG.

The products shown herein are not designed for use in life-saving or life-sustaining applications unless otherwise

expressly indicated. Customers using or selling VPG products not expressly indicated for use in such applications do

so entirely at their own risk and agree to fully indemnify VPG for any damages arising or resulting from such use or sale.

Please contact authorized VPG personnel to obtain written terms and conditions regarding products designed for such

applications.

Product names and markings noted herein may be trademarks of their respective owners.

Document No.: 63999

Revision: 15-Jul-2014

www.vpgsensors.com

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >
