F-219 (Rev 11NOV19)
HCMD–10–S–03.00–01
(2.54 mm) .100"
IDC SOCKET & TERMINAL CABLE
Mates with:
TSW, MTSW, TST, EW,
BST, ZST, MTLW, TSM,
EJH-02 (HCSD only)
TYPE
STRIP
ROW
OPTION
NO. PINS
PER ROW
END
ASSEMBLY
ASSEMBLED
LENGTH
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?HCSD
or www.samtec.com?HCSS
= Single
S
HCSD, HCSS
Insulator Material:
Black Liquid Crystal Polymer
Flammability Rating:
UL 94V-O
Insulation Resistance:
5000 MΩ
Temperature Range:
-20 °C to +105 °C
(Rainbow Cable)
-40 °C to +105 °C (Gray Cable)
Voltage RAting:
425 VAC/600 VDC
Contact:
Phosphor Bronze
Plating:
10 µ" (0.25 µm) Au on
contact area, 150 µ" (3.81 µm)
Sn on balance over
50 µ" (1.27 µm) Ni.
Lead Size Range:
.024" (0.61 mm) SQ to
.026" (0.66 mm) SQ
Lead Insertion Depth:
.185" (4.70 mm) to
.250" (6.35 mm)
Wire:
28 AWG 7/36 stranded
Tinned Copper
RoHS Compliant:
Yes
= Double
(Color coded cable N/A
for 36 pins/row.
See –G option.)
D
–05, –08,
–10, –12,
–13, –15,
–17, –20
= Assembled Length
–“XX.XX”
Assembled Length in
INCHES (±1/8")
2 inches minimum
= Male Strip
(3.30)
.130
(5.08)
.200
HCM
–S
= Single End
No. of Positions x .100 (2.54)
+ .180 (4.57)
(7.87)
.310
REF
(0.51)
.020
(0.64)
.025
SQ
TYP
(2.54)
.100
A
(2.54)
.100
Double
(HCMD)
Socket or Male Plug on one end
Single
(HCMS)
–D
= Double End
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?HCMD
or www.samtec.com?HCMS
LEAD
STYLE
–01
–02
A
(3.05) .120
(5.84) .230
HCMD, HCMS
Insulator Material:
Black Liquid Crystal Polymer
Flammability Rating:
UL 94V-O
Insulation Resistance:
5000 MΩ
Temperature Range:
-20 °C to +105 °C
(Rainbow Cable)
-40 °C to +105 °C (Gray Cable)
Voltage RAting:
425 VAC/600 VDC
Terminal:
Phosphor Bronze
Plating:
Sn over 50 µ" (1.27 µm) Ni
Wire:
28 AWG 7/36 stranded
Tinned Copper
RoHS Compliant:
Yes
Note:
IDC assemblies are
non-standard, non-returnable.
= Socket Strip
HCS
Socket or Male Plug on each end
No. of Positions x .100 (2.54)
+ .180 (4.57)
(3.30)
.130
(5.08)
.200
–T
= Transfer End
(9.53)
.375
REF
(0.76)
.030
SQ.
Single
TYP.
(HCSS)
(2.54)
.100
(2.54)
.100
Double
(HCSD)
Male Plug on one end with socket on other.
Begin part number with HCM.
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
HCSS–15–S–03.00–01–G
HCSD–10–S–03.00–01–T–G
HCMD, HCMS, HCSD, HCSS SERIES
LEAD
STYLE
PLATING
OPTION
NOTCH
POLARIZATION
OTHER
OPTIONS
–N
= Notch Polarization
= HCSS/HCSD or
(3.05 mm) .120" tail for
HCMS/HCMD
–01
–02
= 10 µ" (0.25 µm) Gold on contact area or tail,
Tin on balance
(Standard on HCSS & HCSD. Leave blank)
–S
–T
(1.27)
.050
02
01
(3.81) .150
= (5.84 mm) .230" tail
HCMS/HCMD only
= Tin
(Standard on HCMS & HCMD. Leave blank)
Required for HCSS and HCSD.
(Not available on HCMS or HCMD,
unless Transfer, then only the
socket is polarized.)
= Position Polarization
– P “XX”
= Stripped & Tinned
Specify Suffix from table. All
dimensions are ±
1
/
16
" (1.59 mm). Not
available in 28 positions and higher.
– ST “X”
= Daisy Chain Single
(50.80)
2.00
min.
–S “XX”
= Reversed
–R
“XX”
±
1
/
8
" (3.18)
Single Row
Connectors
02
04
01
03
02
04
01
03
Outer Most
(End of
Assembly)
(101.60)
4.00 minimum
–ST8
–ST4
–ST2
–ST3
/
8
"
(3.18)
1
/
4
"
(6.35)
1
/
2
"
(12.70)
3
/
8
"
(9.53)
1
Single
Double
When mating double row connector
with two single row connectors, the
outer most single will be connected
to Conductor #1 and the inside single
to Conductor #2.
6
3
7
= Middle Reversed
–M
Specify “XX” as position. For Double
the same position will be polarized
on both ends. (Not available on
HCM, unless Transfer, then only the
socket is polarized)
– B “XX”
= Breakout
Specify “XX” as number of
conductors to be broken out.
= Daisy Chain, Double
(50.80)
2.00
min.
– D “XX”
“XX”
±
1
/
8
" (3.18)
Double Row
Strips
Requires –SXX, –WXX or –DXX
7
1
“XX”
(127.00)
5.00 max.
Breakout starts with Number 1
lead indicated by brown wire or
(50.80)
red stripe. Shown on top side.
2.00 min.
Outer Most
(End of
Assembly)
= Gray Cable
–G
(101.60)
4.00 minimum
= Outside Reversed
6
–O
4
Standard cable is color coded. Specify
–G for Gray cable with one red edge.
= Reversed Wiring
Same as –S “XX” except outer strip
connected to conductor #2 and inside
strip connected to conductor #1.
5
6
–RW
= Wiring Reversed
Daisy Chain, Single
–W “XX”
Requires –SXX, –WXX or –DXX
7
#1 wire opposite position #1
2
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
