SFR25H006653FA100 datasheet, PDF

Datasheet> All Categories > Passive components> The resistor> SFR25H006653FA100

SFR25H006653FA100: DescriptionRESISTOR, METAL FILM, 0.5 W, 1 %, 100 ppm, 665000 ohm, THROUGH HOLE MOUNT, AXIAL LEADED, ROHS COMPLIANT; CategoryPassive components The resistor; File Size149KB，9 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

SFR25H006653FA100 Overview

RESISTOR, METAL FILM, 0.5 W, 1 %, 100 ppm, 665000 ohm, THROUGH HOLE MOUNT, AXIAL LEADED, ROHS COMPLIANT

SFR25H006653FA100 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1696287572
package instruction	,
Reach Compliance Code	compliant
Country Of Origin	India, South Korea
ECCN code	EAR99
YTEOL	6.65
JESD-609 code	e3
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package shape	TUBULAR PACKAGE
method of packing	AMMO PACK
Rated power dissipation(P)	0.5 W
Rated temperature	70 °C
resistance	665000 Ω
Resistor type	FIXED RESISTOR
surface mount	NO
technology	METAL FILM
Temperature Coefficient	100 ppm/°C
Terminal surface	Matte Tin (Sn)
Terminal shape	WIRE
Tolerance	1%
Operating Voltage	350 V

Preview

Download Datasheet

View All

SFR16S/25/25H

Vishay BCcomponents

Standard Metal Film Resistors

FEATURES

•

Low cost

•

Low noise (max. 1.5 µV/V for

> 1 MΩ)

•

Small size (SFR16S-0204, SFR25/25H-0207)

A homogeneous film of metal alloy is deposited on a high

grade ceramic body. After a helical groove has been cut in

the resistive layer, tinned connecting leads of electrolytic

copper are welded to the end-caps.

The resistors are coated with a colored lacquer (light-blue for

type SFR16S; light-green for type SFR25 and red-brown for

type SFR25H) which provides electrical, mechanical and

climatic protection. The encapsulation is resistant to all

cleaning solvents, in accordance with

“MIL-STD-202E,

method 215”,

and

“IEC 60068-2045”.

•

Lead (Pb)-free solder contacts

•

Pure tin plating provides compatibility with lead (Pb)-free

and lead containing soldering processes

•

Compatible with “Restriction of the use of Hazardous

Substances” (RoHS) directive 2002/95/EC (issue 2004)

APPLICATIONS

•

General purpose resistors

TECHNICAL SPECIFICATIONS

DESCRIPTION

VALUE

SFR16S

± 5 %; 1

to 3 MΩ

Resistance range

± 1 %; 4.99

to 3 MΩ

jumper (0

Ω)

Resistance tolerance

Temperature coefficient:

4.7

Ω ≤

≤

100 kΩ

100 kΩ <

≤

1 MΩ

Absolute maximum dissipation at

amb

= 70 °C

Thermal resistance,

Maximum permissible voltage

Noise:

68 kΩ

≤

100 kΩ

≤

1 MΩ

Basic specifications

Climatic category (IEC 60068)

Stability,

ΔR

max., after:

load:

range

climatic tests:

≤

1 MΩ

Soldering

Short time overload

± (1 %

+ 0.05

Ω)

± (1 %

+ 0.05

Ω)

± (0.25 %

+ 0.05

Ω)

± (0.25 %

+ 0.05

Ω)

± (1 %

+ 0.05

Ω)

± (1 %

+ 0.05

Ω)

± (0.25 %

+ 0.05

Ω)

± (0.25 %

+ 0.05

Ω)

± (1 %

+ 0.05

Ω)

± (2 %

+ 0.1

Ω)

± (0.25 %

+ 0.05

Ω)

± (1 %

+ 0.05

Ω)

± (2 %

+ 0.05

Ω)

± (2 %

+ 0.05

Ω)

± (2 %

+ 0.05

Ω)

max. 0.1 µV/V

max. 0.5 µV/V

max. 1.5 µV/V

max. 0.1 µV/V

max. 1.5 µV/V

IEC 60115-1 and 60115-2

55/155/56

max. 0.1 µV/V

max. 1.5 µV/V

≤

± 250 x 10

-6

≤

± 100 x 10

-6

≤

± 250 x 10

-6

≤

± 250 x 10

-6

0.5 W

170 K/W

200 V

≤

± 100 x 10

-6

≤

± 100 x 10

-6

≤

± 100 x 10

-6

≤

± 250 x 10

-6

0.4 W

200 K/W

250 V

≤

± 100 x 10

-6

≤

± 100 x 10

-6

≤

± 100 x 10

-6

≤

± 250 x 10

-6

0.5 W

150 K/W

350 V

SFR25

SFR25H

± 5 %; 0.22

to 10 MΩ

± 1 %; 1

to 10 MΩ

jumper (0

Ω)

± 1 %, E24/E96 series; ± 5 %, E24 series

Note:

•

value is measured with probe distance of 24 ± 1 mm using 4-terminal method

www.vishay.com

For technical questions, contact: ff3dresistors@vishay.com

Document Number: 28722

Revision: 03-Dec-07
