"B" DIA.
PART NO.
±.010 [±0.25]
CSP4-01
CSP6-01
CSP8-01
.295 [7.5]
.394 [10.0]
.436 [11.0]
"C" DIA. "D" REF. "E" REF.
----
.29 [7.3]
.33 [8.3]
----
.12 [3.0]
.14 [3.6]
.10 [2.5]
.20 [5.0]
.22 [5.5]
MOUNTING
HOLE DIA.
±.003 [±0.08]
.195 [5.0]
.256 [6.5]
.272 [6.9]
RECOMMENDED
SCREW SIZE
#4 [M2.5]
#6 [M3.5]
#8 [M4]
PART NO.
CSR4-224-01
CSR4-295-01
CSR4-394-01
CSR4-591-01
CSR4-787-01
CSR6-224-01
CSR6-295-01
CSR6-394-01
CSR6-591-01
CSR6-787-01
CSR8-224-01
CSR8-295-01
CSR8-394-01
CSR8-591-01
CSR8-787-01
"A" DIA.
±.010 [±0.25]
.224 [5.7]
.295 [7.5]
.394 [10.0]
.591 [15.0]
.787 [20]
.224 [5.7]
.295 [7.5]
.394 [10.0]
.591 [15.0]
.787 [20]
.224 [5.7]
.295 [7.5]
.394 [10.0]
.591 [15.0]
.787 [20]
"B" DIA.
±.010 [±0.25]
M A TING
PA RT NO.
.295 [7.5]
CSP4-01
"B"
"C"
"D"
"B"
.394 [10.0]
CSP6-01
"E"
"A"
.436 [11.0]
CSP8-01
CSR (RETAINER)
MOUNTING HOLE DIA.
CSP(PIN)
CSP
.093 2.4 MAX.
BD. THICKNESS
CSR
NOTES:
1. MATERIAL: NYLON 6/6 (RMS-01).
2. COLOR: NATURAL.
TITLE:
CREATED USING
SOLIDWORKS
TYPICAL ASSEMBLY
COLLAR SPACERS
FILE #: CSP-CSR
SHEET: 1 OF 1
SHEET SIZE: A
RE:
DWN: R.S
DT: 04/07/95
APP: -
CHKD: -
PART #
DWG IN
IN [MM]
FINAL
F
-
REV.
SEE ECN #817 FOR CHANGES
SEE ENGINEERING FOR REV. A-E
DESCRIPTION
SM
07/06/04
--
----
ENGR. DATE
TOLERANCES
UNLESS NOTED
.XX=±.010
.XXX=±.005
FRAC.=±1/64
ANG.=±1°
RICHCO, INC.
RICHCO, INC.
ENG@RICHCO-INC.COM
(773) 539-4060
SEE TABLE
CA
PRINT
TYPE
