CAUTION
LEVEL
COLOR:
SYMBOL:
PACKAGED:
White with blue printing
JEDEC JEP 113
250 per roll, 3" diameter core
This Bag Contains
MOISTURE-SENSITIVE DEVICES
If blank, see adjacent
bar code label
1. Calculated shelf life in sealed bag: 12 months at <40°C and <90%
relative humidity (RH).
2. Peak package body temperature:________________________°C
If blank, see adjacent bar code label
3. After bag is opened, devices that will be subjected to reflow solder
or other high temperature process must
a) Mounted within ____________________hrs of factory conditions
If blank, see adjacent bar code label
≤30°C/60%
RH, OR
b) Stored at
≤10%
RH.
4. Devices require baking, before mounting, if :
a) Humidity Indicator Card is >10% when read at 23 ±5°C.
b) If 3a or 3b are not met.
5. If baking is required, devices may be baked for 48 hrs. at 125±5°C
Note: If device containers cannot be subjected to high temperature
or shorter bake times are desired.
reference IPC/JEDEC J-STD-033 for bake
Bag Seal Date:_______________________________________________
If blank, see adjacent bar code label
DESCRIPTION:
The product is designed for dry packing applications; the label
provides the moisture warning symbol and displays a warning message needed
to complete your dry package system. The label is tamper evident, allowing you
to easily monitor whether or not the MBB has been opened. The permanent
adhesive label is designed for use on all Protektive Pak Statshield
®
Moisture
Barrier Bags that are used in the dry packing of SMD tape and reel, quad flat
pack/JEDEC trays, and component shipping tubes
PRODUCT SPECIFICATIONS:
Adhesive:
Liner:
Facestock:
Service Temperature:
Minimum Labelling Temperature:
B-82, strong and permanent
40# white Kraft
60# SemiGloss Litho
-10 to +180°F
+15°F
Note: Level and body temperature
defined by IPC/JEDEC J-STD-020
STATSHIELD
®
SERIES
www.descoindustries.com
Moisture Warning
Symbol and
message clearly
shown on label.
INK & VARNISH SPECIFICATIONS:
Water Resistance:
Excellent
Grease Resistance:
Excellent
Alcohol Resistance:
Excellent
UV Resistance:
Excellent
Item
47508
Description
3" x 3", Permanent
Qty/Roll
250
FEATURES
250 labels per roll
White label with blue printing
Coated with an ultra violet varnish for added durability
Strong, permanent adhesive
Labels are mounted on a 3" core for use in tape dispensers
Tamper evident
Made in America
LABEL, MOISTURE SENSITIVE, CAUTION, JEDEC JEP 113
PROTEKTIVE PAK
13520 MONTE VISTA AVENUE, CHINO, CA 91710
PHONE (909) 627-2578, FAX (909) 363-7331
www.protektivepak.com
© 2005 DESCO INDUSTRIES INC.
Employee Owned
DRAWING NUMBER
47508
DATE:
7/05
