Corcom Product Guide
Catalog: 1654001
Issue Date: 06.2011
3-phase WYE RFI Power Line Filters for High Noise Applications
AYC Series
UL Recognized*
150AYC10B
AYC Series
• For 3-phase, four wire, WYE applications
• Very high attenuation
• Low leakage current
• Ideal for EMC troubleshooting and refurbishing in
the field
• Touch safe terminals provide easy connections
and prevent inadvertent contact for safety in the
most demanding applications
Specifications
Maximum leakage current each Line to Ground:
120 VAC 60Hz
277 VAC 50Hz
16A
25 & 36A
63A
80, 100 & 150A
180, 200A
Hipot rating (one minute):
Line to Ground:
Line to Line:
Line to Neutral:
Rated Voltage (max):
Phase to Phase:
Phase to Ground:
Operating Frequency:
Rated Current:
62 mA
68 mA
74 mA
74 mA
111 mA
106
118
128
129
192
mA
mA
mA
mA
mA
Ordering Information
150 AYC 10 B -95
Terminal Block Option
-95 – 95mm terminal block
available on 150A only
1850 VDC
1850 VDC
1450 VDC
480 VAC
277 VAC
50/60 Hz
16 to 200A
Omit for standard terminals
Filter Type
B – Single stage
Input / Output Style
10 – Terminal block
AYC Series
Current Rating
16, 25, 36, 63, 80, 110,
150, 180 or 200A
Operating Ambient Temperature Range
(at rated current Ir):
-10°C to +40°C
In an ambient temperature (Ta) higher than +40°C
the maximum operating current (Io) is calculated as
follows: Io = Ir
(85-Ta)/45
Electrical Schematic
A
B
C
LINE
LOAD
A
B
C
N
GND
Available Part Numbers
16AYC10B
25AYC10B
36AYC10B
63AYC10B
80AYC10B
108
110AYC10B
150AYC10B
150AYC10B-95
180AYC10B
200AYC10B
N
GND
*All except 200AYC10B
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Corcom Product Guide
Catalog: 1654001
Issue Date: 06.2011
3-phase WYE RFI Filters for High Noise Applications
(continued)
AYC Series
Case Styles
16, 25, 36, 63AYC10B
Case Dimensions
Part No.
16AYC10B
B D
A
B
C
D
E
E
A
C
80, 110, 150AYC10B / -95
25AYC10B
36AYC10B
63AYC10B
80, 110 &
150AYC10B
150AYC10B-95
180AYC10B
200AYC10B
2
Three Phase Filters
B D
Terminals
Part No.
Terminal
Ground
Size
M5
4mm²
terminal block
Torque max.
lbf-in [N-m]
E
A
26.58 [3.0]
7.08 [0.8]
26.58 [3.0]
15.93 [1.8]
26.58 [3.0]
15.93 [1.8]
53.1 [6.0]
20.35 [2.3]
177.0 [20.0]
70.80 [8.0]
177.0 [20.0]
177.0 [20.0]
16AYC10B
Line / Load
Ground
C
M5
6mm²
terminal block
25AYC10B
Line / Load
Ground
M5
10mm²
terminal block
180, 200AYC10B
36AYC10B
Line / Load
Ground
B D
M6
16mm²
terminal block
63AYC10B
Line / Load
E
A
E
80, 110,
150AYC10B
Ground
Line / Load
M10
50mm²
terminal block
C
150AYC10B-95
Ground
180AYC10B
Line / Load
200AYC10B
M10
95mm²
terminal block
109
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Corcom Product Guide
3-phase WYE RFI Filters for High Noise Applications
Catalog: 1654001
Issue Date: 06.2011
(continued)
AYC Series
Performance Data
Typical Insertion Loss
Measured in closed 50 Ohm system
16AYC10B
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
25AYC10B
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
36AYC10B
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
63AYC10B
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
80AYC10B
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
110AYC10B
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
150AYC10B
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
180, 200AYC10B
db
100
90
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
30
Frequency in MHz
Common Mode / Asymmetrical (L-G)
Differential Mode / Symmetrical (L-L)
Minimum Insertion Loss
Measured in closed 50 Ohm system
Common Mode / Asymmetrical (Line to Ground)
Differential Mode / Symmetrical (Line to Line)
110
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
