1. PHYSICAL DIMENSIONS
REVISION
REV.
B
DESCRIPTION
RoHS Compliancy
DATE
06-01-06
APPROVED
LY
ELECTRICAL CHARACTERISTICS:
1-1.
VOLTAGE RATING...................................115/250VAC
1-2.
CURRENT RATING
A. @ 115 VAC........................................5 A RMS MAX
B. @ 250 VAC........................................5 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.25 mA MAX
B. @ 250 VAC 50Hz.............................0.45 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
.01
7
1
.05
8
5
.10
25
6
.15
40
12
.50
60
60
1.0
65
65
5.0
65
60
10
60
54
30
45
46
Ø0.188
2.06MAX
1-3.
1-4.
1-5.
2.94 ± 0.02
3.34MAX
3.75MAX
1-6.
FREQ. MHz
COM. MODE dB
DIF. MODE dB
1-7.
OPERATING TEMPERATURE.................-25° TO +100° C
SAFETY:
RoHS COMPLIANT
1.15MAX
1-8.
1-9.
2. ELECTRICAL SCHEMATIC
Dim
range
(mm)
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
L: 1.6mH
C1: 0.22uF
C2: 3300pF
R: 2.2MΩ
PPC DIVISION
854-05/009
EMI FILTER
UNIT: in
0-1
1-6
6-18
18-50
50-120
120-250
250-500
REV. B
Approved / Date
JJH / 07-15-03
Drawn / Date
B.Zhang
07-15-03
Checked / Date
07-15-03
