Automotive SM Crystal (AEC-Q200)
Specifications
2011/65/EU
GRX-530
Parameters
Product
GRX-530
9.80 ~ 40.0MHz
±10ppm
±15ppm
±20ppm
Other values
±15ppm
±20ppm
±50ppm
±100ppm
Other values
A
B
D
F
specify
F
1
P
2
specify
P
2
5
C
specify
4
A
specify
Option
Codes
Frequency range:
Calibration tolerance:
Temperature stability:
5.00
±0.15
3.20
±0.15
0.70
±0.20
Operating temperature range:
-40 to +85°C
-40 to +125°C
Other values
SOLDER PAD LAYOUT
Storage temperature range:
-40 to +125°C
Circuit condition:
10pF
12pF
16pF
20pF
Other values
Fundamental
5pF max
1
4
2
3
1.40
4
1
3
2
1.30
1.00
1.30
2.60
1.60 2.20 1.60
TOP VIEW
PAD
1
2
3
4
CONNECTION
Crystal
Ground & lid
Crystal
Ground & lid
Oscillation mode:
Static capacitance (C
0
):
Features
Equivalent series resistance (max):
60Ω (9.80 ~ 10.99MHz)
50Ω (11.0 ~ 11.99MHz)
40Ω (12.0 ~ 24.99MHz)
30Ω (25.0 ~ 40.0MHz)
Ageing:
±3ppm max first year
AEC-Q200 qualified for automotive apps
Seam sealed for excellent long-term stability
High reliability at low cost
Metal lid can be grounded to minimise EMI
Test drive level:
10μW typ, 100μW max
Soldering condition:
260°C, 10 sec x2 max
Standard.
Optional - Please specify required code(s) when ordering
Example Applications
Ordering Information
Product name + option codes + frequency
eg:
GRX-530/P24DF 13.560MHz
15/20/-40+85/16-F
GRX-530/25ABF 27.0MHz
20/50/-40+125/12-F
Option code X (eg GRX-530/X) denotes a custom specification.
Vehicle telematics
Connected car
Remote Keyless Entry (RKE)
Audio - DAB / Bluetooth
Camera
Tel:
+44 1460 256 100
08 Oct 2015
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
Product Information
Construction
GRX-530
Ceramic body with gold-plated pads
Metal lid, seam sealed
Composition
This product is lead-free, and is fully compliant with
the RoHS directive 2011/65/EU
2011/65/EU
Pb
LeadFree
Packaging & Handling
Production quantities supplied on T&R, 1k pcs per reel.
Small quantities may be supplied on tape (no reel), or in bulk.
Soldering Profile
°C
260°C ±5°C
10s max
Marking
FREQUENCY
S DC
Marking type: Laser
DC = Date code in YM, eg
“EB”
= Feb 2015
260
200
5°C/s max
A
B
C
D
E
F
G H
J
K
L M
Y
1
2
3
4
5
6
7
8
9
0
M Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec
100
5°C/s max
Tape & Reel Specification
3.5
±0.05
4.0 2.0
1.50Ø
±0.05
Preheat
140~160°C
1.75
0
90s max
200s max
Heat
> 200°C
40s max
Slow
cooldown
Time
0.3
5°
±0.05
MARK
5.5
5.3
12.0
±0.2
Maximum solder resistance: 260
°
C x 10 secs x 2.
1.1
8.0
2.2
120°
2.0
20.2Ø
180Ø
FEED
12.4
-0.0
+2.0
13Ø
62Ø
Not to scale. Dimensional tolerances ±0.1mm unless otherwise stated.
Tel:
+44 1460 256 100
08 Oct 2015
Fax:
+44 1460 256 101
E-mail:
sales@golledge.com
Web:
www.golledge.com
