Ferrites and Accessories PQ Cores

Series/Type:

PQ 20/20

The following products presented in this data sheet are being withdrawn.

Ordering Code

B65876E1014D001

Substitute Product

Date of Withdrawal

2010-12-10

Deadline Last

Orders

2011-03-31

Last Shipments

2011-06-30

For further information please contact your nearest EPCOS sales office, which will also support you in selecting a

suitable substitute. The addresses of our worldwide sales network are presented at www.epcos.com/sales.

Ferrites and Accessories

PQ20/20/14-1 – Cores and coil former

B65875A, B65876E

Cautions and warnings

Mechanical stress and mounting

Ferrite cores have to meet mechanical requirements during assembly and for a growing number of

applications. Since ferrites are ceramic materials one has to be aware of their special behavior under

mechanical load.

Just like any ceramic material, ferrite cores are brittle and sensitive to any shock, fast changing or

tensile load. Especially fast cooling rates under ultrasonic cleaning, high static and cyclic loads can

cause cracks or failure of the ferrite cores.

For detailed information see Data Book 2007, chapter “General – Definitions, 8.1”.

Effects of core combination on AL value

Stresses in the core affect not only the mechanical but also the magnetic properties. It is apparent

that the initial permeability is dependent on the stress state of the core. The higher the stresses are in

the core, the lower the value for the initial permeability. Thus, the embedding medium should offer the

greatest possible elasticity.

For detailed information see Data Book 2007, chapter “General – Definitions, 8.2”.

Heating up

Ferrites can run hot during operation at higher flux densities and higher frequencies.

NiZn-materials

The magnetic properties of NiZn-materials can change irreversibly when exposed to strong magnetic

fields.

Processing notes

– The start of the winding process should be soft. Otherwise, the flanges may be destroyed.

– Excessive winding forces may damage the flanges or squeeze the tube so that the cores can no

longer be mounted.

– Excessive soldering time at high temperature (>300 °C) may affect coplanarity or pin arrangement.

– Not following the processing notes for soldering of the J-leg terminals may cause solderability

problems at the transformer because of contamination with tin oxide (SnO) from the tin bath or

burned insulation from the wire. For detailed information see Data Book 2007, chapter “Processing

notes, 2.2”.

– The dimensions of the pin hole arrangement are fixed and should be understood as an ideal

recommendation for drilling the printed circuit board. In order to avoid problems when

mounting the transformer, customers should make allowances for manufacturing tolerances in

the drilling and pick-and-place processes by increasing the diameter of the pin holes.

KA IN FER D PD, SMP IN FER D PD

Please read

Cautions and warnings

and

Important notes

at the end of this document.
