PM 114/93
Core
■
To IEC 61247
■
For power transformers
B65733
>1 kW (20 kHz) and energy storage chokes
■
Delivery mode: sets
Magnetic characteristics
(per set)
l/A
l
e
A
e
A
min
V
e
= 0.116 mm
–1
= 200 mm
= 1720 mm
2
= 1380 mm
2
= 344000 mm
3
Approx. weight
1940 g/set
Gapped
Material
A
L
value
nH
N27
630
3%
6300
15%
s
approx.
mm
3.80
0.22
e
Ordering code
58
583
B65733A0630A027
B65733A6300L027
Ungapped
Material
A
L
value
e
P
V
Ordering code
nH
N27
N87
16000 +30/–20% 1480
16000 +30/–20% 1480
W/set
< 14.0 (100 mT, 25 kHz, 100
C)
B65733A0000R027
< 10.0 ( 50 mT, 100 kHz, 100
C)
B65733A0000R087
Please read
Cautions and warnings
and
Important notes
at the end of this document.
2
06/13
PM 114/93
Accessories
Coil former without solder pins
Material:
Polyphenylene sulphide (UL 94 V-0, insulation class to IEC 85:
F max. operating temperature 155
C),
color code black
Ryton R-4,
E233198 (M)
, CHEVRON PHILLIPS CHEMICAL CO L P
see Data Book 2013, chapter “Processing notes, 2.1”
A
N
mm
2
1070
l
N
mm
210
A
R
value
6.75
Ordering code
B65734B1000T001
B65734
Winding:
Sections
1
Please read
Cautions and warnings
and
Important notes
at the end of this document.
3
06/13
Ferrites and accessories
