High Temperature Crystal Oscillator 7.0 x 5.0mm
1.8V/2.5V/3.3V CMOS XO
HX701
7.0 x 5.0mm Ceramic SMD
Package:
(Scale: none; dimensions are in mm)
Product Features
•
Support high temperature up to 105C
•
Low phase jitter - < 1ps RMS max.
•
Wide frequency range - 1.75 ~ 161MHz
•
Thicker crystal for improved reliability
•
Low supply current - 40mA max.
•
Pb-free & RoHS compliant
Recommended Land Pattern:
Product Description
The HX701 XO series is a high performance
CMOS crystal oscillator family that
supports high temperature with very low
jitter performance. It supports various
options including wider frequency range,
1.8V/2.5V/3.3V voltage, and various
stabilities over wide temperature range.
It is designed to meet the clock source
specifications for communication systems,
Industrial applications and other high
performance equipment.
Pin Functions:
Pin
Function
1
2
3
4
OE
Ground
Output
V
DD
Applications
•
Networking systems
•
Industrial systems
•
Profession video equipments
•
Test and measurement
*Extended high frequency power decoupling is recommended (see test circuit for minimum
recommendation). To ensure optimal performance, do not route RF traces beneath the
package.
Part Ordering Information:
HX 701
Voltage:
V
A
I
B
FFFF.FFFFFF
C
1=+3.3V
2=+2.5V
3=+1.8V
Stability and Temp Range:
Stability
A = +/-25 ppm
B = +/-25 ppm
C = +/-25 ppm
D = +/-50 ppm
E = +/-50 ppm
F = +/-50 ppm
Temp Range
-40/+90°C
-40/+100°C
-40/+105°C
-40/+90°C
-40/+100°C
-40/+105°C
Frequency:
FFFF.FFFFFF
MHz, “4 digits/decimal/6 digits” format
SaRonix-eCera™ is a Pericom® Semiconductor company
•
US: +1-408-232-9100 TW: +886-3-4518888
•
www.pericom.com
15-0073
All specifications are subject to change without notice.
HX701
Rev A
03/05/15
1
1.8V/2.5V/3.3V CMOS XO
HX701
High Temperature Crystal Oscillator 7.0 x 5.0mm
Electrical Performance
Parameter
Min.
Typ.
Max.
Units
Notes
Output Frequency
Supply Voltage
1.75
3.135
2.375
1.71
3.3
2.5
1.8
161
3.465
2.625
1.89
20
40
100
±50
MHz
V
See ordering options
1.75MHz to 60MHz
> 60MHz
See ordering options
See ordering options
Supply Current, Output Enabled
Supply Current, Output Disabled only
Frequency Stability
Operating Temperature Range
Output Logic 0, V
OL
Output Logic 1, V
OH
Output Load
Duty Cycle
Rise and Fall Time, Measured 20/80% of
waveform
Jitter, Accumulated, RMS (1-σ)
Jitter, Phase, RMS
Jitter, pk-pk
< 40MHz
>=40MHz
45
0.9 V
DD
-40
mA
uA
ppm
°C
V
V
pF
%
ns
ps
ps
ps
+105
0.1 V
DD
15
55
8
4
4
1
1
40
Measured 50% V
DD
1.75MHz to 60MHz
> 60MHz
20.000 adjacent periods
12kHz to 5 MHz frequency band
12kHz to 20 MHz frequency band
100,000 random periods
Notes:
1. Stability includes all combinations of operating temperature, load changes, rated input (supply) voltage changes, initial calibration tolerance (25°C),
aging (1 year at 25°C average effective ambient temperature), shock and vibration.
2. For specifications other than those listed, please contact sales.
Output Enable / Disable Function
Parameter
Min.
Typ.
Max.
Units
Notes
Input Voltage (pin 1), Output Enable
Input Voltage (pin 1), Output Disable (low power standby)
Output Disable Delay
Output Enable Delay
Start up Time
0.7 V
DD
0.3 V
DD
200
10
10
V
V
ns
ms
ms
or open
Output is Hi-Z
Absolute Maximum Ratings
Parameter
Min.
Typ.
Max.
Units
Notes
Storage Temperature
-55
+125
°C
For the latest product information visit:
http://www.pericom.com/products/crystals-and-crystal-oscillators/cxo/?part=HX701
For test circuit go to:
http://www.pericom.com/pdf/sre/tc_cmos2.pdf
For soldering reflow profile and reliability test ratings go to:
http://www.pericom.com/pdf/sre/reflow.pdf
For tape and reel information go to:
http://www.pericom.com/pdf/sre/tr_7050_xo.pdf
SaRonix-eCera™ is a Pericom® Semiconductor company
•
US: +1-408-232-9100 TW: +886-3-4518888
•
www.pericom.com
15-0073
All specifications are subject to change without notice.
HX701
Rev A
03/05/15
2
