Fox Part Number: 119-29.4912-21202
HCMOS, CERAMIC, SMD, OSCILLATOR
MODEL: F4101R
RoHS Compliant / Pb Free
Specifications
Parameter
Frequency
Frequency Stability
1
Temperature Range
Operating
(T
OPR
)
Storage
(T
STG
)
Supply Voltage (V
DD
)
Input Current
(I
DD
)
During Disable
(Standby)
Output Symmetry (50% V
DD
)
Rise Time (10% ~ 90% V
DD
)
(TR)
Fall Time (90% ~ 10% V
DD
)
(TF)
Output Voltage (V
OL
)
(V
OH
)
Output Current (I
OL
)
(I
OH
)
Output Load
(HCMOS)
Start-up Time
(T
S
)
Output Disable Time
2
Output Enable Time
2
Maximum Soldering Temp / Time
Moisture Sensitivity Level (MSL)
Termination Finish:
Weight
(TYP)
ENABLE/DISABLE FUNCTION
Pin 1
OUTPUT (Pin 3)
2
OPEN
ACTIVE
ACTIVE
'1' Level VIH
70%V
DD
High Z
'0' Level VIL
30%V
DD
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load
change, aging, shock, and vibration.
2
An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
NOTE: A 0.01µF bypass capacitor should be placed between V
DD
(Pin 4) and GND
(Pin 2) to minimize power supply line noise.
1
2
Mechanical / Dimensions (millimeters):
29.4912 MHz
±100 PPM
-40°C ~ +85ºC
-55°C ~ +125ºC
5.0V ± 10%
18 mA Max
10 µA Max
40% ~ 60%
5 nS Max
5 nS Max
10%V
DD
Max
90%V
DD
Min
2 mA Min
-2 mA Min
15 pF Max
10 mS Max
150 nS Max
10 mS Max
260°C / 10 Seconds
1
Au
138.7 mg
7.5 Max
#4
#3
5.2 Max
#1
#2
1.5 Max
1.4±0.2
#1
#4
#2
#3
5.08±0.1
2.6±0.2
Recommended
Solder Pad Layout
1.8±0.1
2.0±0.1
4.2±0.1
5.08±0.1
Pin Connections
#1 E/D #3 Output
#2 GND #4 V
DD
Drawing is for reference to critical specifications
defined by size measurements. Certain non-critical
visual attributes, such as side castellations,
reference pin shape, etc. may vary.
Date Code
A
= 2002
B
= 2003
C
= 2004
D
= 2005
E
= 2006
F
= 2007
A
= Jan
B
= Feb
C
= Mar
D
= Apr
E
= May
F
= Jun
NOTE: The above specifications, having been carefully prepared and checked, is believed to be accurate at the time of publication; however, no
responsibility is assumed by Fox Electronics for inaccuracies.
Reference / Comments
Title / Description:
Product Specifications
Initial release
Rev:
1
Size:
A
Drawing Number: DWG-6753
Cage:
61429
Part Number: 119-29.4912-21202
Draftsperson: AR
Approved: CR
Date: 07-28-2011
Page 1 of 1
