T-1 3/4 (5mm) SPRIAL ROUND LED LAMPS
L-433HDT BRIGHT RED
L-433IDT HIGH EFFICIENCY RED
L-433SRDT SUPER BRIGHT RED
L-433GDT GREEN
L-433EDT ORANGE
L-433YDT YELLOW
Features
!
5mm
!
LOW
Description
The Bright Red source color devices are made with Gallium
Phosphide Red Light Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
The High Efficiency Red and Orange source color devices
are made with Gallium Arsenide Phosphide on Gallium
Phosphide Orange Light Emitting Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
The Super Bright Red source color devices are made
with Gallium Aluminum Arsenide Red Light Emitting Diode.
DIAMETER, SPRIAL LENS.
POWER CONSUMPTION.
AND RUGGED.
!
RELIABLE
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: KDA0155
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: SEP/30/2001
DRAWN: X.M.Zhou
PAGE: 1 OF 6
Selection Guide
Iv (m c d )
@ 10 m A*20m A
Min .
L-433HDT
L-433IDT
L-433EDT
L-433GDT
L-433YDT
L-433SRDT
BRIGHT RED (GaP)
HIGH EFFICIENCY RED (GaAsP/GaP)
ORANGE (GaAsP/GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
SUPER BRIGHT RED (GaAlAs)
RED DIFFUSED
RED DIFFUSED
ORANGE DIFFUSED
GREEN DIFFUSED
YELLOW DIFFUSED
RED DIFFUSED
0.7
3
3
2
2
*50
Ty p .
1
8
8
5
4
*100
V i ew i n g
An g l e
2θ1/2
10 0 °
10 0 °
10 0 °
10 0 °
10 0 °
10 0 °
Par t No .
Dic e
L en s Ty p e
Notes:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. * Luminous intensity with asterisk is measured at 20mA.
°
Electrical / Optical Characteristics at T
)
=25°C
Sy m b o l
Par am et er
D ev i c e
Bright Red
High Efficiency Red
Orange
Green
Yellow
Super Bright Red
Bright Red
High Efficiency Red
Orange
Green
Yellow
Super Bright Red
Ty p .
700
627
627
565
590
660
660
625
625
568
588
640
45
45
45
30
35
20
40
15
15
15
20
45
2.25
2.0
2.0
2.2
2.1
1.85
2.5
2.5
2.5
2.5
2.5
2.5
10
Max .
Un it s
Tes t Co n d it io n s
λ
peak
Peak Wavelength
nm
IF=20mA
λ
D
Dominate Wavelength
nm
IF=20mA
∆λ
1/2
Bright Red
High Efficiency Red
a
Spectral Line Halfwidth Orenge
Gr en
Yellow
Super Bright Red
Bright Red
High Efficiency Red
Orange
Green
Yellow
Super Bright Red
Bright Red
High Efficiency Red
Orange
Green
Yellow
Super Bright Red
All
nm
IF=20mA
C
Capacitance
pF
VF=0V;f=1MHz
V
F
Forward Voltage
V
IF=20mA
I
R
Reverse Current
uA
V R = 5V
SPEC NO: KDA0155
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: SEP/30/2001
DRAWN: X.M.Zhou
PAGE: 2 OF 6
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
B r ig h t
R ed
120
25
120
5
Hig h
E f f i c i en c y
R ed
105
30
16 0
5
Or an g e
10 5
30
16 0
5
Gr een
105
25
14 0
5
-40
°
C To +85
°C
Yello w
105
30
140
5
S u p er
B r ig h t
R ed
100
30
155
5
Un it s
mW
mA
mA
V
260
°
C For 5 Seconds
Bright Red L-433HDT
SPEC NO: KDA0155
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: SEP/30/2001
DRAWN: X.M.Zhou
PAGE: 3 OF 6
