PRECISION 5.0 VOLT MICROPOWER
VOLTAGE REFERENCE
ISSUE 3 - NOVEMBER 2002
ZR4040-5.0
DEVICE DESCRIPTION
The ZR4040-5.0 uses a bandgap circuit
design to achieve a precision micropower
voltage reference of 5.0 volts. The device
is available in a small outline surface
mount package, ideal for applications
where space saving is important, as well
as packages for through hole
requirements.
The ZR4040-5.0 design provides a stable
voltage without an external capacitor and
is stable with capacitive loads. The
ZR4040-5.0 is recommended for operation
between 60µA and 15mA and so is ideally
suited to low power and battery powered
applications.
Excellent performance is maintained to an
absolute maximum of 25mA, however the
rugged design and 20 volt processing
allows the reference to withstand transient
e ffe cts a nd currents up to 200mA.
Superior switching capability allows the
device to reach stable operating
conditions in only a few microseconds.
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Small outline SOT23 package
TO92 style package
No stabilising capacitor required
Typical T
C
20ppm/°C
Typical slope resistance 0.33Ω
2% and 1% tolerance
Automotive temperature range
Operating current 60µA to 15mA
Transient response,stable in less than
10µs
APPLICATIONS
Battery powered and portable
equipment.
Metering and measurement systems.
Instrumentation.
Test equipment.
Data acquisition systems.
Precision power supplies.
SCHEMETIC DIAGRAM
9
5
*
QG
4-181
ZR4040-5.0
ABSOLUTE MAXIMUM RATING
Reverse Current
Forward Current
Operating Temperature
Storage Temperature
25mA
25mA
-55 to 125°C
-55 to 125°C
Power Dissipation (T
amb
=25°C)
SOT23
330mW
E-Line, 3 pin (TO92)
500mW
ELECTRICAL CHARACTERISTICS
TEST CONDITIONS (Unless otherwise stated) T
amb
=25°C
SYMBOL PARAMETER
CONDITIONS
MIN
V
R
I
MIN
I
R
T
C
†
Reverse Breakdown Voltage
I
R
=150µA
4.95
4.90
LIMITS
TYP
5.0
5.0
30
0.06
-40 to 85°C
I
R(min)
to
I
R(max)
-55 to 125°C
I
R(min)
to
I
R(max)
20
MAX
5.05
5.10
60
15
100
1
2
V
µA
mA
ppm/°C
TOL. % UNITS
Minimum Operating Current -55 to 125°C
Recommended Operating
Current
Average Reverse
Breakdown Voltage Temp.
Co.
Average Reverse
Breakdown Voltage Temp.
Co.
Slope Resistance
Reverse Dynamic
Impedance
Wideband Noise Voltage
I
R
= 1mA
f = 100Hz
I
AC
= 0.1 I
R
I
R
= 1mA
f = 10Hz to
10kHz
T
C
†
40
125
ppm/°C
R
S
§
Z
R
0.33
0.4
1.5
1.0
Ω
Ω
E
N
105
µV
(rms)
V
R
x
(T
(max)
−T
(min)
)
†
T
C
=
(V
R(max)
−V
R(min)
)
x
1000000
m
Note: V
R(max)
- V
R(min)
is the maximum
deviation in reference voltage measured
over the stated operating temperature
range.
§
R
S
=
V
R
Change
(I
R
(min)
to I
R
(max))
I
R
(max) −
I
R
(min)
7
$
&
7
$
&
Reverse Voltage (V)
5HYHUVH &KDUDFWHULVWLFV
4-182
