INDUSTRIAL GRADE CompactFlash Disk
W7CFxxxA-H Series ROHS 6/6 Compliant
32MB – 16-GB
TM
CompactFlash Disk
INDUSTRIAL GRADE
W7CFxxxA-H Series
TM
INFORMATION IN THIS DOCUMENT IS PROVIDED IN RELATION TO
WINTEC INDUSTRIES PRODUCTS, AND IS SUBJECT TO CHANGE
WITHOUT NOTICE.
NOTHING IN THIS DOCUMENT SHALL BE CONTRUED AS GRANTING
ANY LICENSE, EXPRESS OR IMPLIED.
ALL INFORMATION IN THIS DOCUMENT IS PROVIDED ON AN “AS-IS”
BASIS WITHOUT GUARANTEE OR WARRANTY OF ANY KIND.
Please contact your nearest Wintec representative for the latest updates or additional product
information.
WintecCF-W7CF-H_v2.10 ROHS
January 2011
Wintec Industries, Inc.
1
INDUSTRIAL GRADE CompactFlash Disk
W7CFxxxA-H Series ROHS 6/6 Compliant
32MB – 16-GB
TM
Revision History
Revision
2.0
2.1
Month
February
June
Year
2006
2006
History
-ROHS Spec Release
-Add Title Page & Revision History
-Update Table 28: Identify Drive Information
-Update Table 37: Attribute Memory Read AC Characteristics
-Update Table 38: Attribute Memory Write AC Characteristics
-Update Table 28: Identify Drive Information
-Update Tables 37~42
-Update Table 43: True IDE Mode I/O Read/Write Timing
-Update Table 44: True IDE DMA Mode I/O Read/Write Timing
-Update Figures 14~19
-Update Figure 20: True IDE Mode I/O Timing Diagram
-Update Figure 21: True IDE DMA Mode I/O Timing Diagram
-Update Table 37 Attribute Memory Read Timing
-Update Table 38 Attribute Memory Write Timing
-Update Table 39 I/O Access Read Timing
-Update Table 41 Common Memory Access Read Timing
-Update DMA pins‟ description, Pin 43 DMARQ and 44 DMACK
-Update Table 7 Layout
-Update new naming scheme for the CF card
-Update Table 48 Ordering Information and naming guide
-Add section 4.1 Labeling and Marking
-Add 16GB capacity to the specification
-Update table 48 with 8GB Real Capacity
-Update table 48 key with firmware options
-Update the ordering information with firmware options
2.2
June
2006
2.3
December
2006
2.4
2.5
2.6
2.7
2.8
2.9
2.10
May
March
May
October
November
January
January
2007
2008
2008
2008
2008
2009
2010
WintecCF-W7CF-H_v2.10 ROHS
January 2011
Wintec Industries, Inc.
2
INDUSTRIAL GRADE CompactFlash Disk
W7CFxxxA-H Series ROHS 6/6 Compliant
32MB – 16-GB
TM
CompactFlash
TM
Card
INDUSTRIAL GRADE
WxCFxxxA-H Series ROHS 6/6 Compliant
Features
GENERAL
Type I Density up to 16-GB
32-bit RISC/DSP Controller
Solid State Data Storage
Dual 3.3V / 5V Interface
Industry Standard Compatibility
Specialized for High-Reliability
ROHS 6/6 Compliant
True IDE Mode Capable
–
PIO Mode 0-4
–
DMA Mode 0-2 (Optional)
High Performance 16.7 MB/s Burst
Low Power Consumption
ATA-2 Compliant (w/DMA Enable)
> 2,000,000 Program/Erase Cycles
Industrial Wear Leveling
- Includes Static Block Management
Spares & Bad Block Management
On-Board ECC
–
Corrects up to 6-bytes/Sector
High Environmental Tolerance
10-Year Data Retention
Unlimited Reads
CFA Spec, Revision 4.1, Feb 2007
PCMCIA PC Card Standard, 7.0, February 1999
PCMCIA PC Card ATA Spec, 7.0, Feb 1999
PERFORMANCE
Wintec Type I CompactFlash
TM
Card
RELIABILITY
Configuration Options
(PHOTO)
Industrial Temperature
Fixed / Removable Disk
DMA Mode Enable
Data Programming Service
Custom Labeling
NOTE:
1.
See Section 5.0 for Configuration & Ordering Guide
COMPATIBILITY
DESCRIPTION
The Wintec Industries W7CFxxxA-H series of ROHS Compliant Industrial Grade CompactFlash
TM
Memory Cards are
constructed with Samsung NAND-type single-level-cell (SLC) flash memory devices paired to a powerful 32-bit RISC/DSP-
based system controller for virtual-to-physical address mapping and other flash management functions.
Wintec Industrial CompactFlash
TM
Cards employ a variety of sophisticated error checking and flash management utilities
allowing for maximum levels of data reliability and card endurance. Patented wear-leveling methods ensure even wear of flash
blocks across the entire card capacity. Background operations track erase counts, prioritize new writes to blocks with lower
wear, and relocate static data to blocks with higher wear. Bad-block Management routines replace worn blocks with spare blocks
reserved by the controller on card initialization. Reed-Solomon based ECC algorithms capable of detecting and correcting up to
6 bytes per 512 byte sector are implemented on the fly without performance degradation to ensure data reliability through user
data transfers and background wear-leveling operations. Additional information regarding the specifics of wear leveling, ECC
methods, and application-specific card life calculations are available upon request and under NDA.
Industrial grade reliability, industry standard compatibility, and the ability to emulate IDE hard disk drives make Wintec
CompactFlash
TM
Cards ideal for industrial, military, and other high endurance applications.
WintecCF-W7CF-H_v2.10 ROHS
January 2011
Wintec Industries, Inc.
1
3
INDUSTRIAL GRADE CompactFlash Disk
W7CFxxxA-H Series ROHS 6/6 Compliant
32MB – 16-GB
TM
Table of Contents
1.0 General Product Specifications
2.0 Card Function Explanation
2.1
2.2
Attribute Access
Task File Register Access
2.2.1
2.2.2
2.2.3
I/O Address Map
Memory Access Map
True IDE Mode
Configuration Option Register
Configuration and Status Register
Pin Replacement Register
Socket and Copy Register
Data Register
Error Register
Feature Register
Sector Count Register
Sector Number Register
Cylinder Low Register
Cylinder High Register
Drive Head Register
Status Register
Alternate Status Register
Command Register
Device Control Register
Drive Address Register
ATA Command Set Description
Sector Transfer Protocol
3
12
13
13
14
15
16
16
17
17
18
18
20
20
20
20
20
20
20
21
21
21
22
22
23
23
24
25
26
2.3
Configuration Register
2.3.1
2.3.2
2.3.3
2.3.4
2.4
Task File Register Specification
2.4.1
2.4.2
2.4.3
2.4.4
2.4.5
2.4.6
2.4.7
2.4.8
2.4.9
2.4.10
2.4.11
2.4.12
2.4.13
2.5
ATA Command Specification
2.5.1
2.5.2
3.0 Electrical Specification
3.1
3.2
3.3
3.4
3.5
General
DC Characteristics
3.2.1
3.3.1
Current Waveform
General
29
29
32
32
34
34
45
46
AC Characteristics
Reset Characteristics
User Notes
4.0 Physical Specifications
5.0 Product Guide & Ordering Information
47
48
WintecCF-W7CF-H_v2.10 ROHS
January 2011
Wintec Industries, Inc.
2
INDUSTRIAL GRADE CompactFlash Disk
W7CFxxxA-H Series ROHS 6/6 Compliant
32MB – 16-GB
TM
1.0 General Product Specification
For all the following specifications, values are defined at ambient temperature and nominal supply voltage unless otherwise
stated.
Table 1: Performance Specifications
Parameter
Burst Transfer Rate To/From Host
Burst Transfer Rate To/From Flash
Sustained Read (Typical)
Sustained Write (Typical)
Active-to-Sleep Delay
Command-to-DRQ (Max.)
Startup Times
Sleep-to-Write (Max.)
Sleep-to-Read (Max.)
Reset-to-Ready (Typical)
Reset-to-Ready (Max.)
Spec
16.6 MB/s
20.0 MB/s
8.0 MB/s
6.0 MB/s
Programmable
50.0 ms
2.5 ms
20 ms
50.0 ms
400.0 ms
NOTE:
1.
All performance figures are based on testing done in True IDE PIO Mode 4.
Table 2: Card Endurance
Parameter
Program/Erase Cycles
Read Cycles
Data Retention
MTBF
Spec
> 2,000,000 Cycles
Unlimited
10 Years (Min.)
> 4,000,000 Hours
Table 3: Card Data Reliability
Parameter
Non-Recoverable Errors
Erroneous Correction
ECC Correctability
ECC Detectability
Spec
< 1 in 10
14
Bytes Read
< 1 in 10
20
Bytes Read
6 Bytes/Sector
6 Bytes/Sector
Table 4: Environmental Specifications
Temperature
Humidity
Vibration
Altitude
Shock
Acoustic
Parameters
Standard Temp.
Industrial Temp.
Operating
0C to 70C
-40C to 85C
8% to 95%
(Non-Condensing)
16.3 G rms
80,000 ft. (Max.)
2,000 G (Max.)
0 db
Non-Operating
-55C to 95C
-55C to 95C
8% to 95%
(Non-Condensing)
N/A
Table 5: Power Consumption
Capacity
32MB
64MB
128MB
256MB
512MB
1-GB
2-GB
4-GB
8-GB
Sleep (Max)
300
300
300
300
450
450
600
600
600
Read/Write
(Typical)
40 mA
40 mA
40 mA
40 mA
45.02mA
45.02mA
45.06mA
45.06mA
45.06mA
Read/Write
(Max)
50 mA
50 mA
50 mA
50 mA
60.10mA
60.10mA
60.30mA
60.30mA
60.30mA
NOTE:
1.
Input voltage 3.3V (5%) or 5V (10%) with a maximum ripple of 100mV peak-to-peak.
2.
All values listed are at 25C and nominal supply voltage.
3.
Stated figures are based on primary configurations and may vary as larger density component NAND flashes are released.
WintecCF-W7CF-H_v2.10 ROHS
January 2011
Wintec Industries, Inc.
3
