10/100Base-T Multi-Port Switch Module
iMcV-Switch
PRODUCT FEATURES
the user to increase port density and the service area of Ethernet
networks. The store and forward switch function allows the end user to
extend Ethernet service to locations for a total of 100 meters from the
Ethernet source. All RJ-45 ports Auto Negotiate 10/100Base-T, half/full
port allows a maximum frame size of up to 1916 bytes and supports
Flow Control and priority queuing.
configuration of copper and fiber ports, copper and fiber SFP ports and
an all copper port version.
ORDERING INFORMATION
MODEL
FIBER RANGE
FIBER
NUMBER
PORTS
iMcV-Switch *
852-14440
100 m
852-14441
SFP
1
852-14442
SFP
2
852-14443
MM850-ST
1
2 km
852-14444
MM850-SC
1
2 km
852-14445
MM1300-ST
1
5 km
852-14446
MM1300-SC
1
5 km
852-14449
SM1310/PLUS-ST
1
40 km
852-14450
SM1310/PLUS-SC
1
40 km
852-14451
SM1310/LONG-ST
1
80 km
852-14452
SM1310/LONG-SC
1
80 km
852-14453
SM1550/LONG-SC
1
80 km
852-14454
1
100 km
SINGLE STRAND FIBER **
852-14470
852-14471
(1310xmt/1550rcv)
(1550xmt/1310rcv)
(1310xmt/1550rcv)
(1550xmt/1310rcv)
(1310xmt/1550rcv)
(1550xmt/1310rcv)
1
1
1
1
1
1
20 km
20 km
40 km
40 km
60 km
60 km
ETHERNET ETHERNET
PORTS
CONNECTOR
5
4
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
RJ45
iView: Windows 2000/XP/Vista/Win7
852-14472
852-14473
852-14474
852-14475
* SFPs Sold Separately
* These products have single-strand fiber technology. Deploy in pairs or connect another compatible
B&B IMC LLC single-strand fiber product.
WWW
.
BB
-
ELEC
.
COM
|
10/100Base-T Multi-Port
Switch Module
iMcV-Switch
SPECIFICATIONS
TECHNICAL
IEEE 802.3x 10/100Base-T
IEEE 802.3u Auto Negotiation
RFC-2474 and RFC-2475 DiffServ/ToS
Includes diagnostic LEDs
AutoCross and Auto Negotiation on all ports
Maximum 1916 byte packet size
Supports Half and Full-Duplex operation
Connectors: RJ-45 and SC, ST, LC or SFP
Installs in any iMediaChassis, MediaChassis or IE-MediaChassis
Supports GUI-Based iView²
Supports Half- and Full-Duplex operation
Includes diagnostic LEDs
Includes hot-swappable architecture
MECHANICAL
Dimensions
Shipping Weight
ENVIRONMENTAL
Operating Temperature:
Storage Temperature:
Operating Humidity
REGULATORY APPROVALS
FCC Class B
UL/cUL
CE
4.19”H x 0.78”W x 2.75”D
(
(10.74 x 2 x 7.05 cm)
)
0.30 lbs (.11 kg)
+32° to +122° F (0° to +50° C)
-4° to +158° F (-20° to +70° C)
5% to 95% (non-condensing),
0 – 10,000 ft. altitude
MECHANICAL DIAGRAM
(dimensions in inches )
.10
.76
1.24
.62
3.35
4.19
3.57
.62
1.46
.85
.57
.76
.31
.12
