Technical Data Sheet
3294-15USOC/S530-AX
Features
˙Popular
T-1 package.
˙High
efficiency.
˙General
purpose leads.
˙Selected
minimum intensities.
˙Available
on tape and reel.
˙Pb
free
Descriptions
˙The
series is specially designed for applications
requiring higher brightness.
˙The
LED lamps are available with different
colors, intensities, epoxy colors, etc.
˙Superior
performance in outdoor environment
Applications
˙Status
indicators.
˙Commercial
use.
˙Advertising
Signs.
˙Back
lighting.
Device Selection Guide
LED Part No.
3294-15USOC/S530-A3
3294-15USOC/S530-A4
3294-15USOC/S530-A5
AlGaInP
Super Sunset Orange
Water Clear
Chip
Material
Emitted Color
Lens Color
Everlight Electronics Co., Ltd.
Device Number : DLE-329-009
http\\:www.everlight.com
Prepared date: 07-23-2004
Rev 1.0
Page: 1 of 5
Prepared by: Bob Kam
3294-15USOC/S530-AX
Package Dimensions
Notes:
˙Other
dimensions are in millimeters, tolerance is 0.25mm except being specified.
˙Protruded
resin under flange is 1.5mm Max LED.
˙Bare
copper alloy is exposed at tie-bar portion after cutting.
Absolute Maximum Rating (T
a
=25℃)
Parameter
Forward Current
Pulse Forward Current
(Duty1/10@ 1KHz)
Operating Temperature
Storage Temperature
Electrostatic Discharge
Soldering Temperature
Power Dissipation
Reverse Voltage
Symbol
I
F
I
FP
T
opr
T
stg
ESD
T
sol
P
d
V
R
Absolute Maximum Rating
25
60
-40 ~ +85
-40 ~ +100
2000
260
±
5
60
5
Unit
mA
mA
℃
℃
V
℃
mW
V
Notes: Soldering time≦5 seconds.
Everlight Electronics Co., Ltd.
Device Number : DLE-329-009
http\\:www.everlight.com
Prepared date: 07-23-2004
Rev 1.0
Page: 2 of 5
Prepared by: Bob Kam
3294-15USOC/S530-AX
Electro-Optical Characteristics (T
a
=25℃)
Parameter
Symbol
*Chip
Rank
A3
Luminous Intensity
I
V
A4
A5
Viewing Angle
Peak Wavelength
Dominant Wavelength
Spectrum Half width
Forward Voltage
Reverse Current
2θ
1/2
λ
p
λ
d
Δλ
V
F
I
R
--
--
--
--
--
--
Min.
40
50
63
--
--
--
--
--
--
Typ.
63
80
100
90
621
615
18
2.0
--
Max.
--
--
--
--
--
--
--
2.4
10
V
μA
V
R
=5V
nm
deg
I
F
=20mA
mcd
Unit
Condition
*3294-15USOC/S530-AX
Chip Rank
Everlight Electronics Co., Ltd.
Device Number : DLE-329-009
http\\:www.everlight.com
Prepared date: 07-23-2004
Rev 1.0
Page: 3 of 5
Prepared by: Bob Kam
3294-15USOC/S530-AX
Typical Electro-Optical Characteristics Curves
Relative Intensity vs. Wavelength
1.0
Forward Current vs. Forward Voltage
25
Relative Intensity(a.u.)
0.8
Forward Current(mA)
550
600
650
700
20
0.6
15
0.4
10
0.2
5
0.0
500
0
1.0
1.5
2.0
2.5
3.0
3.5
Wavelength(nm)
Forward Voltage(V)
Relative Intensity vs. Ambient Temp
2.0
Forward Current vs. Relative Intensity
1.5
Relative Intensity(a.u.)
1.5
Relative Intensity(a.u.)
30
35
40
45
50
55
60
O
1.0
1.0
0.5
0.5
0.0
25
65
70
0.0
0
5
10
15
20
25
Ambient Temperature Ta( C)
Forward Current(mA)
Forward Current vs. Ambient Temp.
90
30
O
Radiation Characteristics
60
O
30
O
0
O
10
O
1.0
20
O
Relative Luminusity
30
O
Forward Current(mA)
25
20
15
10
5
0
40
O
O
50
0.5
60
O
70
O
80
0
O
0
20
40
60
80
O
100
0
Ambient Temperature Ta( C)
0.5
90
1.0
O
Radiation Angle
Everlight Electronics Co., Ltd.
Device Number : DLE-329-009
http\\:www.everlight.com
Prepared date: 07-23-2004
Rev 1.0
Page: 4 of 5
Prepared by: Bob Kam
3294-15USOC/S530-AX
Packing Quantity Specification
1.1000PCS/1Bag，4Bags/1Box
2.10Boxes/1Carton
Label Form Specification
EVERLIGHT
CPN:
P/N:
3294-15USOC/S530-AX
QTY：
CAT:
HUE:
LOT NO：
REF:
MADE IN TAIWAN
CPN: Customer’s Production Number
P/N : Production Number
3294-15USOC/S530-AX:Production name
QTY: Packing Quantity
CAT: Ranks of Luminous and Forward Voltage
HUE: Ranks of Dominant Wavelength
REF: Reference
LOT No: Lot Number
MADE IN TAIWAN: Production Place
Notes
1. Above specification may be changed without notice. EVERLIGHT will reserve authority on
material change for above specification.
2. When using this product, please observe the absolute maximum ratings and the instructions
for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for
any damage resulting from use of the product which does not comply with the absolute
maximum ratings and the instructions included in these specification sheets.
3. These specification sheets include materials protected under copyright of EVERLIGHT
corporation. Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT’s
consent.
EVERLIGHT ELECTRONICS CO., LTD.
Office: No 25, Lane 76, Sec 3, Chung Yang Rd,
Tucheng, Taipei 236, Taiwan, R.O.C
Tel: 886-2-2267-2000, 2267-9936
Fax: 886-2267-6244, 2267-6189, 2267-6306
http:\\www.everlight.com
Everlight Electronics Co., Ltd.
Device Number : DLE-329-009
http\\:www.everlight.com
Prepared date: 07-23-2004
Rev 1.0
Page: 5 of 5
Prepared by: Bob Kam
