SURFACE MOUNT LED LAMP
SUPER BRIGHT 1206
QTLP650C-R
Red
QTLP650C-Y
Yellow
QTLP650C-IB
Blue
PACKAGE DIMENSIONS
0.133 (3.4)
0.117 (3.0)
R0.016 (0.4)
0.071 (1.8)
0.055 (1.4)
QTLP650C-E
Orange
QTLP650C-AG
Yellow-Green
QTLP650C-O
Yellow-Orange
QTLP650C-IG
True Green
TOP
CATHODE
0.087 (2.2)
0.071 (1.8)
0.051 (1.3)
0.035 (0.9)
0.024 (0.6)
SIDE
0.024 (0.6)
BOTTOM
+
POLARITY
-
APPLICATIONS
• Keypad backlighting
• Push-button backlighting
NOTE:
Dimensions for all drawings are in inches (mm).
• LCD backlighting
DESCRIPTION
These surface mount chip LEDs are designed to fit industry standard footprint. Low profile and wide viewing angle make these
LEDs ideal choices for backlighting applications and panel illumination.
FEATURES
• Small footprint - 3.2(L) X 1.6(W) X 1.1(H) mm
• AllnGaP technology for -R, -E, -O, -Y and -AG
• InGaN/SiC technology for -IG and -IB
• Wide viewing angle of 140°
• Water clear optics
• Moisture-proof packaging
• Available in 0.315” (8mm) width tape on 7” (178mm) diameter reel; 2,000 units per reel
2001 Fairchild Semiconductor Corporation
DS300100
8/30/01
1 OF 8
www.fairchildsemi.com
SURFACE MOUNT LED LAMP
SUPER BRIGHT 1206
QTLP650C-R
Red
QTLP650C-Y
Yellow
QTLP650C-IB
Blue
ABSOLUTE MAXIMUM RATINGS
Parameter
Continuous Forward Current
Peak Forward Current
(f = 1.0 KHz, Duty Factor = 1/10)
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Time
(T
A
=25°C Unless otherwise specified)
QTLP650C
-O
30
160
5
72
-40 to +85
-40 to +90
260 for 5 sec
Units
mA
mA
V
mW
°C
°C
°C
QTLP650C-E
Orange
QTLP650C-AG
Yellow-Green
QTLP650C-O
Yellow-Orange
QTLP650C-IG
True Green
Symbol
I
F
I
FM
V
R
P
D
T
OPR
T
STG
T
SOL
-R
30
160
5
72
-E
30
160
5
72
-Y
25
120
5
60
-AG
30
160
5
72
ABSOLUTE MAXIMUM RATINGS
Parameter
Continuous Forward Current
Peak Forward Current
(f = 1.0 KHz, Duty Factor = 1/10)
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Time
(T
A
=25°C Unless otherwise specified)
QTLP650C
-IB
30
100
5
120
-40 to +85
-40 to +90
260 for 5 sec
-IG
30
100
5
120
Units
mA
mA
V
mW
°C
°C
°C
Symbol
I
F
I
FM
V
R
P
D
T
OPR
T
STG
T
SOL
www.fairchildsemi.com
2 OF 8
8/30/01
DS300100
SURFACE MOUNT LED LAMP
SUPER BRIGHT 1206
QTLP650C-R
Red
QTLP650C-Y
Yellow
QTLP650C-IB
Blue
ELECTRICAL / OPTICAL CHARACTERISTICS
Part Number
Luminous Intensity (mcd)
Minimum
Typical
Forward Voltage (V)
Maximum
Typical
Wavelength (nm)
Peak
Dominant
Spectral Line Half Width (nm)
Viewing Angle (°)
Symbol
-R
25
70
2.4
2.0
630
624
20
140
(T
A
=25°C)
QTLP650C
-O
25
70
2.4
2.0
610
605
18
140
Condition
QTLP650C-E
Orange
QTLP650C-AG
Yellow-Green
QTLP650C-O
Yellow-Orange
QTLP650C-IG
True Green
-E
25
70
2.4
2.0
620
615
18
140
-Y
25
70
2.4
2.0
590
589
15
140
-AG
15
30
2.4
2.0
575
573
20
140
I
V
I
F
= 20mA
V
F
I
F
= 20mA
P
D
I
F
= 20mA
I
F
= 20mA
I
F
= 20mA
2
1/2
ELECTRICAL / OPTICAL CHARACTERISTICS
Part Number
Luminous Intensity (mcd)
Minimum
Typical
Forward Voltage (V)
Maximum
Typical
Wavelength (nm)
Peak
Dominant
Spectral Line Half Width (nm)
Viewing Angle (°)
Symbol
(T
A
=25°C)
QTLP650C
-IB
35
45
4.0
3.5
465
470
25
140
-IG
100
140
4.0
3.5
520
525
35
140
Condition
I
V
I
F
= 20mA
V
F
I
F
= 20mA
P
D
I
F
= 20mA
I
F
= 20mA
I
F
= 20mA
2
1/2
DS300100
8/30/01
3 OF 8
www.fairchildsemi.com
SURFACE MOUNT LED LAMP
SUPER BRIGHT 1206
QTLP650C-R
Red
QTLP650C-Y
Yellow
QTLP650C-IB
Blue
TYPICAL PERFORMANCE CURVES
(QTLP650C-R, -E, -O, -Y and -AG)
Fig. 1 Forward Current vs. Forward Voltage
100
90
80
70
60
50
40
30
20
10
0
1.0
1.5
2.0
2.5
3.0
2.5
QTLP650C-E
Orange
QTLP650C-AG
Yellow-Green
QTLP650C-O
Yellow-Orange
QTLP650C-IG
True Green
Fig. 2 Relative Luminous Intensity
vs. DC Forward Current
RELATIVE LUMNOUS INTENSITY
(NORMALIZED AT 20 mA)
I
F
- FORWARD CURRENT (mA)
2.0
1.5
1.0
0.5
0.0
0
10
20
30
40
50
VF - FORWARD VOLTAGE (V)
I
F
- DC FORWARD CURRENT (mA)
Fig. 3 Relative Intensity vs. Peak Wavelength
1.0
AG
Y
O
E
R
RELATIVE INTENSITY
0.5
0
500
550
600
650
700
WAVELENGTH (nm)
Fig.4 Radiation Diagram
I
F
- FORWARD CURRENT (mA)
50
40
Fig.5 Maximum Forward Current
vs. Ambient Temperature
-30˚
-40˚
-50˚
-60˚
-70˚
-80˚
-20˚ -10˚
0˚ 10˚
20˚
30˚
40˚
50˚
60˚
70˚
80˚
R, E, O and AG
30
20
10
0
Y
-90˚
90˚
1.0 0.8 0.6 0.4 0.2 0 0.2 0.4 0.6 0.8 1.0
QTLP650C
QTLP650D
REL. LUMINOUS INTENSITY (%)
0
25
50
75
100
AMBIENT TEMPERATURE T
A
(˚C)
www.fairchildsemi.com
4 OF 8
8/30/01
DS300100
SURFACE MOUNT LED LAMP
SUPER BRIGHT 1206
QTLP650C-R
Red
QTLP650C-Y
Yellow
QTLP650C-IB
Blue
TYPICAL PERFORMANCE CURVES
(QTLP650C-IG and IB)
Fig. 1 Forward Current vs. Forward Voltage
100
90
80
70
60
50
40
30
20
10
0
2.0
2.5
3.0
3.5
4.0
4.5
5.0
IG
IB
2.5
QTLP650C-E
Orange
QTLP650C-AG
Yellow-Green
QTLP650C-O
Yellow-Orange
QTLP650C-IG
True Green
Fig. 2 Relative Luminous Intensity
vs. DC Forward Current
RELATIVE LUMNOUS INTENSITY
(NORMALIZED AT 20 mA)
I
F
- FORWARD CURRENT (mA)
2.0
1.5
1.0
0.5
0.0
0
10
20
30
40
50
V
F
- FORWARD VOLTAGE (V)
I
F
- DC FORWARD CURRENT (mA)
Fig. 3 Relative Intensity vs. Peak Wavelength
IB
1.0
IG
RELATIVE INTENSITY
0.5
0
400
450
500
550
600
650
WAVELENGTH (nm)
Fig.4 Radiation Diagram
I
F
- FORWARD CURRENT (mA)
50
40
30
20
10
0
Fig.5 Maximum Forward Current
vs. Ambient Temperature
-30˚
-40˚
-50˚
-60˚
-70˚
-80˚
-20˚ -10˚
0˚ 10˚
20˚
30˚
40˚
50˚
60˚
70˚
80˚
-90˚
1.0 0.8 0.6 0.4
0.2 0
0.2
0.4 0.6 0.8 1.0
90˚
0
25
50
75
100
REL. LUMINOUS INTENSITY (%)
AMBIENT TEMPERATURE T
A
(˚C)
DS300100
8/30/01
5 OF 8
www.fairchildsemi.com
