The Bridgelux family of LED Array products delivers high performance, compact and cost-effective solid-
state lighting solutions to serve the general lighting market. These products combine the higher efficacy,
lifetime, and reliability benefits of LEDs with the light output levels of many conventional lighting sources.
The Bridgelux ES Array Series enables lamp and luminaire designs surpassing efficacy and quality of
light requirements driven by regulatory standards with reasonable system design margins, enabling
lighting product compliance to Energy Star, DLC, Title 24, Part L and other global standards.
The Bridgelux ES Array products are a high performance alternative to conventional solid state solutions,
delivering between 700 and 3000 lumens under application conditions in warm, neutral and cool white
color temperatures. These compact high flux density light sources deliver uniform high quality
illumination without pixilation or the multiple shadow effect caused by LED component based solutions.
To simplify system design for appropriate light output, Bridgelux LED Arrays are specified to deliver
performance under typical use conditions.
These integrated plug and play solutions reduce system complexity and enable miniaturized cost-
effective lamp and luminaire designs. Lighting system designs incorporating these LED Arrays deliver
comparable performance to that of 60-200 Watt incandescent and halogen, 7-42 Watt compact
fluorescent, and 18-50 Watt HID based luminaires and feature increased system level efficacy and
service life. Typical applications include replacement lamps, task, accent, spot, retail, track, down light,
low bay, wide area, security, wall pack and street lighting.
Features
•
•
•
•
•
•
•
•
•
•
Compact high flux density light source
Uniform high quality illumination
Minimum 70, 80 and 90 CRI options
Streamlined thermal path
Energy Star / ANSI compliant color
binning structure with 3SDCM options
More energy efficient than incandescent,
halogen and fluorescent lamps
Low voltage DC operation
Instant light with unlimited dimming
5-Year warranty
RoHS compliant and Pb free
Benefits
•
•
•
•
•
•
•
•
Enhanced optical control
Clean white light without pixilation
High quality true color reproduction
Significantly reduced thermal resistance
and increased operating temperatures
Uniform consistent white light
Lower operating costs
Increased safety
Easy to use with daylight and motion
detectors to enable increased energy
savings
Reduced maintenance costs
Environmentally friendly, no disposal issue
•
•
1 0 1 P o rt o l a A v e n u e , L i v e rm o re , C A 9 4 5 5 1 • T e l : (9 2 5 ) 5 8 3 -8 4 0 0 • Fa x: (9 2 5 ) 5 8 3 -8 4 0 1 • ww w. b ri d g e l u x. c o m
Table of Contents
Product Nomenclature
Average Lumen Maintenance Characteristics
IES LM-80 Test Data
Environmental Compliance
UL Recognition
Minor Product Change Policy
Cautionary Statements
Case Temperature Measurement Point
Selection Guide
The following configurations are available:
Flux Characteristics
Optical Characteristics
Electrical Characteristics
Absolute Minimum and Maximum Ratings
Absolute Minimum and Maximum Ratings (continued)
Typical Performance at Alternative Drive Currents
Typical Performance at Alternative Drive Currents (continued)
Mechanical Dimensions
Typical Radiation Pattern
Wavelength Characteristics at Rated Test Current, Tj=25°
C
Typical Light Output Characteristics vs. Temperature
Typical Chromaticity Characteristics vs. Temperature
Forward Current Characteristics
Forward Current Characteristics (continued)
Color Binning Information
Design Resources
Page
3
3
3
4
4
4
4
5
6
6
6
9
10
11
12
13
14
15
16
17
19
20
21
22
23
26
Bridgelux ES Rectangle Array Series Product Data Sheet DS24 (10/11/12)
Page 2 of 27
Product Nomenclature
The part number designation for Bridgelux LED Arrays is explained as follows:
BXRA – AB C DEFG – H – IJ - KLM
Where:
BXRA – Designates product family
AB – Designates the nominal ANSI color temperature; 27 = 2700K; 30 = 3000K, etc.
C - Designates minimum CRI; C = 70, E = 80, G = 90
