CLD-AP42 Rev 9A
binning & labeling
Cree Xlamp Ml Family leDs
®
®
inTroDuCTion
This document describes the product nomenclature
required to select and order Cree’s XLamp
®
mL family
of LeDs. XLamp mL family LeDs are tested and sorted
into bins which are then combined into orderable kits
identified by an order code.
All XLamp LeDs are tested and sorted by color and
brightness into a unique bin. each bin contains
LeDs from only one color and brightness group and
is uniquely identified by a bin code. White XLamp
LeDs are sorted by chromaticity (color) and luminous
flux (brightness). Color XLamp LEDs are sorted by
dominant wavelength (color) and luminous flux
(brightness). LeDs are shipped on reels containing
LeDs from one bin and are always labeled with the
appropriate bin code.
Kits contain LeDs from a number of similar bins and
are fully defined by their order codes. A full explanation
of the order codes for XLamp mL family LeDs, as well
as a list of standard order codes, is provided in this
document.
www.CRee.Com/XLAmP
Table oF ConTenTs
Bin and Order-Code Format
............................... 2
Performance Groups – Luminous or Radiant Flux...
3
Performance Groups – Dominant wavelength ....... 4
Performance Groups – Chromaticity .................... 5
Cree’s Standard Chromaticity Regions Plotted on
the 1931 CIe Curve .......................................... 8
Cree’s Standard Cool white Kits Plotted on ANSI
Standard Chromaticity Regions ........................... 9
Cree’s Standard warm and Neutral white Kits
Plotted on ANSI Standard Chromaticity Regions ...11
Cree’s Standard Chromaticity Kits ......................13
Standard order Codes and Bins
mL-B Cool white ..........................................14
mL-B warm white ........................................15
mL-C Parallel, Cool white ..............................16
mL-C Parallel, warm white ............................17
mL-C Series, Cool white ...............................19
mL-C Series, warm white .............................20
mL-C Color .................................................21
mL-e Parallel, Cool white ..............................22
mL-e Parallel, warm white ............................23
mL-e Series, Cool white ...............................25
mL-e Series, warm white .............................26
mL-e Parallel Color .......................................27
mL-e Series Color ........................................29
Copyright © 2009-2014 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®,
the Cree logo and XLamp
®,
are registered trademarks of Cree, Inc. This document is provided for informational purposes only and
is not a warranty or a specification. For product specifications, please see the data sheets available at www.cree.com. For warranty
information, please contact Cree Sales at sales@cree.com.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
xlamp
®
ml Family leds
binning & labeling
bin anD orDer-CoDe ForMaT
Bin codes and order codes are configured in the following manner:
order Code
Series
MLB = ML-B
MLC = ML-C
MLE = ML-E
CRI Configuration
A1 = Typical CRI
H1 = 80 CRI Minimum
P1 = 85 CRI Minimum
U1 = 90 CRI Minimum
Luminous Flux
SSSCCC-BB-HHHH-NNNFGG
Chromaticity
Internal code
Color/Configuration
AWT = White - Parallel
SWT = White - Series
ROY = Royal Blue
BLU = Blue - Parallel
SBL = Blue - Series
GRN = Green - Parallel
SGN = Green - Series
AMB = Amber - Parallel
SAM = Amber - Series
RED = Red - Parallel
SRD = Red - Series
SSSCCC-BB-WWW-FF-A-AAAAA
Internal code
Chromaticity code
Color/Configuration
AWT = White - Parallel
SWT = White - Series
ROY = Royal Blue - Parallel
BLU = Blue - Parallel
SBL = Blue - Series
GRN = Green - Parallel
SGN = Green - Series
AMB = Amber - Parallel
SAM = Amber - Series
RED = Red - Parallel
SRD = Red - Series
Bin Code
Series
MLB = ML-B
MLC = ML-C
MLE = ML-E
CRI Configuration
A1 = Typical CRI
H1 = 80 CRI Minimum
P1 = 85 CRI Minimum
U1 = 90 CRI Minimum
Luminous flux group
Copyright © 2009-2014 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®,
, the Cree logo and XLamp
®,
are registered
trademarks of Cree, Inc. This document is provided for informational purposes only and is not a warranty or a specification. For product specifications, please see the data sheets
available at www.cree.com. For warranty information, please contact Cree Sales at sales@cree.com.
2
xlamp
®
ml Family leds
binning & labeling
PerForManCe grouPs – luMinous or raDianT FluX
White XLamp ML family LEDs are tested for luminous flux and placed into one of the following luminous-flux groups:
group Code
F0*
F2
F3
G2
G3
H2
H3
J2
J3
Min. luminous Flux
10.7
10.7
12.3
13.9
15.8
18.1
20.6
23.5
26.8
Max. luminous Flux
13.9
12.3
13.9
15.8
18.1
20.6
23.5
26.8
30.6
G0
13.9
18.1
H0*
18.1
23.5
J0*
23.5
30.6
K2
K3
m2
m3
N2
N3
N4
P2
P3
30.6
35.2
39.8
45.7
51.7
56.8
62
67.2
73.9
35.2
39.8
45.7
51.7
56.8
62
67.2
73.9
80.6
Notes:
•
Flux codes F0, G0, H0 and J0 are further subdivided into F2, F3, G2, G3 and H2, H3, respectively. Orders for the F0
flux code may be filled with either F2 or F3 sub-codes, orders for the G0 flux code may be filled with either G2 or G3
sub-codes, orders for the H0 flux code may be filled with H2 or H3 sub-codes, and orders for the J0 flux code may
be filled with J2 or J3 sub-codes.
Royal-blue XLamp LEDs are tested for radiant flux and sorted into one of the following radiant-flux bins.
group
03
04
05
06
07
08
09
10
11
12
13
14
Min. radiant Flux (mW)
50
60
70
85
100
122
147
175
210
250
300
350
Max. radiant Flux (mW)
60
70
85
100
122
147
175
210
250
300
350
425
Copyright © 2009-2014 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®,
, the Cree logo and XLamp
®,
are registered
trademarks of Cree, Inc. This document is provided for informational purposes only and is not a warranty or a specification. For product specifications, please see the data sheets
available at www.cree.com. For warranty information, please contact Cree Sales at sales@cree.com.
3
