IL2415S datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> IL2415S

IL2415S: DescriptionDC/DC converter 15v 2W; CategoryPower/power management The power supply circuit; File Size153KB，1 Pages; ManufacturerXP Power; Websitehttps://www.xppower.com/; Environmental Compliance

Download Datasheet Parametric View All

IL2415S Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	IL2415S	-	-	View	Buy Now

IL2415S Overview

DC/DC converter 15v 2W

IL2415S Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Parts packaging code	MODULE
package instruction	SIP-4
Contacts	4
Reach Compliance Code	compli
ECCN code	EAR99
Other features	LG-MAX
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	26.4 V
Minimum input voltage	21.6 V
Nominal input voltage	24 V
JESD-30 code	R-XSMA-T4
length	11.68 mm
Maximum load regulation	10%
Number of functions	1
Output times	1
Number of terminals	4
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	0.132 A
Maximum output voltage	15.45 V
Minimum output voltage	14.55 V
Nominal output voltage	15 V
Package body material	UNSPECIFIED
Encapsulate equivalent code	SIP4,.24
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified
Maximum seat height	10.16 mm
surface mount	NO
technology	HYBRID
Temperature level	INDUSTRIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	SINGLE
Maximum total power output	2 W
Fine-tuning/adjustable output	NO
width	7.5 mm
Base Number Matches	1

Preview

Download Datasheet

View All

2 Watts

IL Series

•

Single Output

SIP Package

1000 VDC Isolation

Optional 3000 VDC Isolation

MTBF >1.2 MHrs

40 °C to +85 °C Operation

3 Year Warranty

DC DC

xppower.com

Specification

Input

Input Voltage Range

Input Reflected

Ripple Current

Input Reverse

Voltage Protection

Input Filter

• Nominal ±10%

• 20 mA pk-pk through 12 µH inductor,

5 Hz to 20 MHz

• None

• Capacitor

Input

Voltage

No Load

Input Current

Output

Voltage

3.3

5.0

9.0

12.0

15.0

24.0

3.3

5.0

9.0

12.0

15.0

24.0

3.3

5.0

9.0

12.0

15.0

24.0

3.3

5.0

9.0

12.0

15.0

24.0

Output

Current

400

222

168

132

400

222

168

132

400

222

168

132

400

222

168

132

Efficiency

71%

77%

80%

82%

72%

78%

82%

84%

82%

74%

80%

84%

72%

78%

82%

80%

82%

Model

Number

(1)

IL0503S

IL0505S

IL0509S

IL0512S

IL0515S

IL0524S

IL1203S

IL1205S

IL1209S

IL1212S

IL1215S

IL1224S

IL2403S

IL2405S

IL2409S

IL2412S

IL2415S

IL2424S

IL4803S

IL4805S

IL4809S

IL4812S

IL4815S

IL4824S

5 VDC

12 VDC

Output

Output Voltage Range

Minimum Load

Line Regulation

Load Regulation

•

See table

None

(2)

1.2%/1%

∆

Vin

±10%, 20-100% load change

(3.3 V models: ±20%)

±3%

150 mV pk-pk max, 20 MHz bandwidth

0.02%/°C

470 µF

24 VDC

Setpoint Accuracy

•

Ripple & Noise

•

Temperature Coefficient

•

Maximum Capacitive

•

Load

48 VDC

General

Efficiency

Isolation Voltage

Isolation Resistance

Isolation Capacitance

Switching Frequency

MTBF

• See table

• 1000 VDC minimum

(3000 VDC -H option)

• 10

• 60 pF typical

• Variable, 70 KHz typical

• >1.21 MHrs to MIL-HDBK-217F

at 25 °C, GB

Mechanical Details

0.46

(11.68) max

0.29

(7.50)

0.40

(10.16) max

Environmental

Operating Temperature

Storage Temperature

Case Temperature

Cooling

Notes

Add suffix ‘H’ to model for 3000 VDC isolation.

Operation at no load will not damage unit but it may not meet all specifications.

All dimensions in inches (mm).

Pin pitch tolerance: ±0.014 (±0.35), Case tolerance: ±0.02 (±0.5)

Weight: 0.004 lbs (1.8 g)

•

-40 °C to +85 °C

-40 °C to +125 °C

100 °C max

Convection-cooled

0.02

(0.51)

0.12

0.10

(3.05) min (2.54)

0.01

(0.25) max

0.30

(7.62)

-Vin +Vin -Vout +Vout

BOTTOM VIEW

0.08

(2.03)

0.02

(0.51)

26-Aug-14
