8
VICOR CONFIDENTIAL
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
7
6
5
4
3
2
REVISIONS
REV
1
2
3
DESCRIPTION
RELEASED PER E053437
DRAWN FOR DEVELOPMENT
REDRAWN PER E100902
DATE
1
APPROVED
EF
REJH
KUK
F
LEK
JS
11/15/05
08/19/09
F
SEE NOTE 6
#30 DRILL THRU
( .1285 )
(6) PL.
DCS
7/14/10
.120
(2) PL.
.300
(2) PL.
E
E
R.110 MAX
(8) PL.
1.47
1.270
D
.10
.650
.130 TYP
SEE NOTE 5
.410
D
.49
1.300
2.280
C
C
.40
-A-
.005
.010
MATL TO BE
REMOVED
.190
.100
B
NOTES:
1.
MATERIAL: EXTRUSION SEE SHEET 2 OF 2
2.
REMOVE ALL BURRS AND SHARP EDGES.
3.
CLEAR FINISH, RoHS COMPLIANT, CHROMIUM FREE PER CST-0001 LATEST REVISION.
"
4.
" DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.
5.
DIMENSIONS APPLIES AT SURFACE -A- (2) PL.
6.
MACHINED SURFACE TO BE .010 MAX BELOW SURFACE -A- (6) PL.
7.
DIMENSIONS ARE INCHES ONLY.
B
DRAWN
D.P.KELLY
MATERIAL
DATE
09/05
VICOR
SWD
A
XXXXX
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE INCH [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HS CFG "C" X-FLOW, .4H
LOW FLOW, THRU HOLE
SIZE
CAGE CODE
DWG NO
REV
A
FINISH
XXXXX
C
DO NOT SCALE DRAWING
67131
30722
SHEET 1 OF 2
3
1
SCALE 2 : 1
8
7
6
5
4
3
2
8
VICOR CONFIDENTIAL
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
7
6
5
4
3
2
REVISIONS
REV
DESCRIPTION
SEE SHEET 1 OF 2
DATE
1
APPROVED
F
F
E
E
3°
1.5 EACH
SIDE OF VERT
R.035
(24) PL.
SEE DETAIL
A
.014
(2) PL.
R.035
R.018
(2) PL.
.023
.036
1.756
D
.410
.200
.235
.110
D
* .056
(2) PL.
* .138
(5) PL.
* .297
* .060
(2) PL.
+.020
2.280
- .000
* .058
(8) PL.
* .133
(6) PL.
R.010
(4) PL.
.031
.040
.080
R.030
(8) PL.
.252
C
C
* .030
* .060
PROFILE COMMON
FOR
30722
32173
30721
30184
B
DETAIL A
SCALE 8 : 1
TYP
B
NOTES:
1.
MATL: ALUMINUM 6063-T5
2.
*DENOTES DIMENSIONS TO THEORETICAL SHARP CORNER
3.
ALL DIMENSIONS ARE CRITICAL CHARACTERISTICS.
4.
RoHS COMPLIANT PER CST-0001 LATEST REVISION.
5.
WORKMANSHIP STANDARDS WS-0004, WS-0006 AND WS-0007 APPLY TO THIS PART.
6.
DIMENSIONS ARE INCHES ONLY.
DRAWN
JSARIPELLA
MATERIAL
DATE
08/19/09
VICOR
SWD
A
SEE NOTES
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE INCH [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HS CFG "C" X-FLOW, .4H, LOW
FLOW, THRU HOLE, EXTRUSION
SIZE
CAGE CODE
DWG NO
REV
A
FINISH
SEE NOTES
C
DO NOT SCALE DRAWING
67131
30722
SHEET 2 OF 2
3
1
SCALE 4 : 1
8
7
6
5
4
3
2
