DESCRIPTION
RELEASED PER E050349
REVISED PER E100622
REVISED PER E100872
REVISED PER E120629
REVISED PER E120794
REVISED PER E131431
PEI
GCK
KUK
ZMB
SJ
GCK
DATE
11/15/05
04/28/10
06/30/10
07/02/12
08/30/12
10/8/13
APPROVED
ECF
REJH
DCS
SJ
REJH
TO
F
E
E
FULL R
(6) PL.
2.080
2.38
D
D
.150
.650
.480
C
1.300
C
.40
.47
.125
B
.055
B
DRAWN BY
P.E.IENI
DATE
05/14/2010
A
NOTES
1. MATERIAL: EXTRUSION SEE SHEET 2 OF 2
2. CLEAR FINISH, RoHS COMPLIANT PER CST-0001, LATEST REVISION PER
A.) CHROMIUM FREE, OR B.) TRIVALENT CHROMIUM IN ACCORDANCE
WITH MIL-DTL-5541, TYPE II, CLASS 1A OR 3. SEE CST-0003 FOR TYPES
OF AVAILABLE FINISHES.
<> 3. REMOVE ALL LOOSE BURRS.
4. MECHANICALLY STAMP OR USE WHITE EPOXY INK FOR PART NUMBER.
REVISION LEVEL NOT REQUIRED, BUT MAY BE INCLUDED AT THE
FABRICATOR'S DISCRETION.
5. <> DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.
6. DIMENSIONS ARE INCHES ONLY.
8
7
6
5
4
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE : INCH / [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HEATSINK XFLOW MINI-MOD .40
HG
SIZE
CAGE CODE
DWG NO
REV
B
DO NOT SCALE DRAWING
67131
2
30140
SHEET 1 OF 2
6
1
A
SCALE 1:1
3
8
VICOR CONFIDENTIAL
7
6
5
4
3
2
REVISIONS
1
F
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR
HEREWITH IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT
THE PERMISSION OF VICOR CORP.
REV
DESCRIPTION
SEE SHEET 1
DATE
APPROVED
F
2.200
1.918
E
.060 TYP
E
1.582
1.268
PROFILE COMMON FOR
.932
FULL R TYP
30140
D
D
.618
R.015 MAX TYP
.282
C
.195
(3) PL
.47
0.005
.125
(4) PL
2.26
C
B
DRAWN BY
P.E.IENI
DATE
05/14/2010
B
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE : INCH / [MM]
A
NOTES:
1.
MATERIAL ALUMINIUM: 6063-T5
2.
BREAK ALL EDGES AND SHARP CORNERS.
3.
RoHS COMPLIANT PER CST-0001 LATEST REVISION.
4.
DIMENSIONS ARE INCHES ONLY.
8
7
6
5
4
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HEATSINK XFLOW MINI-MOD .40
HG
SIZE
CAGE CODE
DWG NO
REV
B
DO NOT SCALE DRAWING
67131
2
30140
SHEET 2 OF 2
6
1
A
SCALE 2:1
3
