DESCRIPTION
RELEASED PER E050350
REVISED PER E100841
REVISED PER E131632
INTL
LEK
KUK
GCK
DATE
11/16/05
06/22/10
11/21/2013
APVD
EF
GCK
TO
F
.15
E
2.40
2.100
FULL R
.125±.010
E
SEE NOTE 4
FULL R
R.015
MAX TYP
D
D
.078
TYP
3.600
.156 TYP
1.800
6 FINS EQ SP @
1.47 X 2 PL
.330
4.60
C
C
.50
.330 TYP
.34 TYP
B
.06 TYP
B
DRAWN BY
Krishna Kamath
DATE
05/14/2010
NOTES:
1. MATERIAL: AL. 6063-T5.
2. REMOVE ALL LOOSE AND HANGING BURRS.
OTHERWISE, BURRS SHALL NOT EXCEED .003.
<> 3. CLEAR FINISH RoHS COMPLIANT PER CST-0001, LATEST REVISION PER: A) CHROMIUM FREE OR
B.) TRIVALEMT CHROMIUM IN ACCORDANCE WITH MIL-D-5541 TYPE II, CLASS 1A OR 3.
SEE CST-0003 FOR TYPES OF AVAILABLE FINISHES.
4. MECHANICALLY STAMP OR USE WHITE OR BLACK EPOXY INK FOR PART NUMBER.
5. <>DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.
6. TOLERANCE ON ALL DIMENSIONS SHOWN AS REFERENCE SHALL FOLLOW
STANDARD ALUMINUM ASSOCIATION TOLERANCE.
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE : INCH / [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HS XF 17.78MM
SIZE
CAGE CODE
DWG NO
REV
A
B
DO NOT SCALE DRAWING
67131
2
30193
SHEET 1 OF 1
3
1
A
SCALE 1:1
8
7
6
5
4
3
