REVISIONS
REV
1
DESCRIPTION
RELEASED PER E050349
DATE
1
APPROVED
ECF
F
PEI
11/15/05
2
3
4.60
3.600
REVISED PER E100841
REVISED PER E101411
KUK 06/22/10
KUK 11/26/10
GCK
REJH
F
.156 TYP
.50
E
1.800
.078 TYP
.15
.70
E
.32
2.100
D
2.40
8 FINS EQ SP @
1.76
D
.06 TYP
.125±.010
C
SEE NOTE 4
FULL R
0.015R MAX TYP
0.005
C
B
B
A
NOTES:
1. MATERIAL: ALUMINUM, 6063-T5, (OR MAKE FROM P/N: 30089 RAW MATERIAL).
2. REMOVE ALL LOOSE AND HANGING BURRS,
OTHERWISE, BURRS SHALL NOT EXCEED .003.
3. CLEAR FINISH, RoHS COMPLIANT, CHROMIUM FREE PER
CST-0001, LATEST REVISION.
4. PERMANENTLY MARK PART NUMBER AND REVISION LEGIBLY IN AREA SHOWN.
5. DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.
6. TOLERANCE ON ALL DIMENSIONS SHOWN AS REFERENCE SHALL FOLLOW
STANDARD ALUMINUM ASSOCIATION TOLERANCE.
8
7
6
5
4
DRAWN
P.E.IENI
MATERIAL
DATE
10/25/05
VICOR
SWD
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE INCH [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
HEATSINK
0.70" HGT. HORIZONTAL
SIZE
CAGE CODE
DWG NO
REV
A
FINISH
C
DO NOT SCALE DRAWING
67131
30775
SHEET 1 OF 1
3
1
SCALE 2 : 1
3
2
