F
F
1
2
.31
7.9
FULL R
E
E
.178
4.52
.93
23.5
.080
2.03
.057
1.45
D
(
0.93
[23.5]
)
UP TO 20° BEND ALLOWED
30°
.035
.89
<>
30°
.018±.003
.46±.08
<>
D
SEE DETAIL 1
.94
23.9
C
.015
.38
FULL R
R.020
.51
DETAIL 1
SCALE 20 : 1
C
MECHANICALLY STAMP
PART NUMBER "33855"
.05 HIGH
APPROX AS SHOWN
THIS SURFACE
B
B
DRAWN BY
R.E.J.Hickey
DATE
05/16/07
VICOR
SWD
A
NOTES:
1. MATERIAL: 260 BRASS, .015 THK, HALF HARD.
2. FINISH: MATTE TIN OR FUSED MATTE TIN, 300-500 MICRO INCHES OVER 100-200 MICRO INCHES NICKEL.
3. RoHS COMPLIANT, LEAD FREE PER CST-0001 LATEST REVISION.
4. <> DENOTES CRITICAL CHARACTERISTIC FOR LOT INSPECTION.
8
7
6
5
4
3
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE : INCH / [MM]
TOLERANCES ARE:
DECIMALS
ANGLES
X.XX [X.X] = ±0.01 [0.25]
±1°
X.XXX [X.XX] = ±0.005 [0.127]
THIRD ANGLE PROJECTION
CLIP HEATSINK GROUNDING
SIZE
A
C
2
CAGE CODE
DWG NO
REV
67131
33855
SHEET 1 OF 1
2
1
DO NOT SCALE DRAWING
SCALE 8:1
