353530-5 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 353530-5

353530-5: DescriptionCONNECTOR, 5 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT; CategoryThe connector The connector; File Size106KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

353530-5 Overview

CONNECTOR, 5 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SURFACE MOUNT

353530-5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	unknow
Connector type	BOARD CONNECTOR
Contact to complete cooperation	TIN LEAD
Contact completed and terminated	TIN LEAD
Contact point gender	MALE
Contact material	BRASS
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e0
MIL compliance	NO
Manufacturer's serial number	353530
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	1.5 mm
Termination type	SURFACE MOUNT
Total number of contacts	5
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Product Feature Selector

> Product Details

353530-5 Product Details

Live Product Chat

1.5mm AMP Mini CT Connectors

Not EU R oHS or ELV C om plia nt

(

Find R oHS C om plia nt Alte rna te s

)

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

353530-5

T E I nternal N umber: 3 5 3 5 3 0 - 5

Product Highlights:

Post Header

Number of Positions = 5

Without Panel Attachment

Terminate To Printed C ircuit Board

PC B Mount Angle = Right Angle

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Superseded

Search for Replacement Parts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

PERSONAL SYSTEMS PRODUC TS

(PDF, English)

Product Specifications:

AMP Mini C ommon Termination (C T) C onnector 1.5mm Pit...

(PDF, English)

AMP Mini C ommon Termination(C T) C onnector

(PDF, English)

Application Specifications:

AMP Mini C ommon Termination (C T) C onnector 1.5mm Pit...

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Post Header

Number of Positions

= 5

PC B Mount Angle

= Right Angle

PC B Mount Style

= Surface Mount

C olor

= Beige

PC B Retention Feature

= No

PC B Mount Polarization

= Without

Post Size (mm [in]) = 0.50 [.020]

PC B Thickness (mm [in]) = 0.80 [0.032]

Mechanical Attachment:

Panel Attachment

= Without

Body Related Features:

Number of Rows

= 1

Heat Resistant Material = Yes

C enterline (mm [in]) = 1.50 [0.059]

Contact Related Features:

C ontact Base Material = Brass

C ontact Mating Area Plating Material = Tin-Lead

C ontact Shape = Square

Housing Related Features:

Housing Material = Nylon GF

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Not suitable for lead free processing

Conditions for Usage:

Terminate To

= Printed C ircuit Board

Packaging Related Features:

Packaging Method

= Tape

Other:

Brand = AMP

Additional Information:

Product Line Information

Additional Product Images:

Recommended PC Board Layout
