ECS-23G
SMD CRYSTAL
The minature ECS-23G is a compact SMD Crystal. The industry
standard 6 x 3.5 x 1.2 mm ceramic package is ideal for GPS, WiFi,
Telecom, and wireless charging applications.
ECS-23G SMD CRYSTAL
Request a Sample
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency
Mode of Oscillation
Frequency Tolerance
Frequency Stability
Shunt Capacitance
Load Capacitance
Drive Level
Operating Temperature
Storage Temperature
Aging (First Year)
Insulation Resistance
Fundamental
@ +25°C
(J)
-40 ~ +85°C
(GN)
CONDITIONS
MIN
ECS-23G
TYP
MAX
UNITS
50.000
± 20
± 30
7
MHz
ppm
ppm
pF
pF
100
+85
+90
±5
μW
°C
°C
ppm
MΩ
ESR Ω Max.
100
80
60
50
8.000
Co
Specify in P/N
D
L
T
opr
T
stg
@ +25°C ±3°C
@100 Vdc
500
Frequency
(MHz)
8.000 ~ 9.999
10.000 ~ 11.999
12.000 ~ 15.999
16.000 ~ 50.000
-40
-40
18
10
•
•
•
•
Low Profile
6.0 x 3.5 mm Footprint
Extended Temp. Range
RoHS Compliant
DIMENSIONS (mm)
Figure 1)
Top, Side, Bottom views
Figure 2)
Suggested land pattern
PART NUMBERING GUIDE: Example ECS-240-18-23G-JGN-TR
ECS - FREQUENCY ABBREVIATION
LOAD
CAPACITANCE
18 = 18 pF
PACKAGE
Tolerance
-23G =
ECS-23G
A = ± 25
ppm
J = ± 20
ppm
*R = ± 15
ppm
*C = ± 10
ppm
CUSTOM OPTIOND
Stability
E = ± 50 ppm
G = ± 30 ppm
H = ± 25 ppm
*T = ± 20 ppm
*W = ± 15 ppm
*K = ± 10 ppm
PACKAGING
Temp Range
L = -10 ~ +70°C
M = -20 ~ +70°C
Y = -30 ~ +85°C
N = -40 ~ +85°C
TR =
Tape
& Reel
1K/Reel
ECS
240 = 24.000 MHz
See P/N Guide
*Contact ECS for availability
Rev.2017
15351 West 109
th
Street
|
Lenexa, KS 66219
|
Phone: 913.782.7787
|
Fax: 913.782.6991
|
www.ecsxtal.com
