DUAL-IN-LINE
SOCKETS
SERIES 113 • SURFACE MOUNT, STUB TAIL W/ ALIGNMENT PINS • OPEN FRAME
0,38-0,64
0,25 * 0,46
B
•
Unique floating contacts compensate for the
•
2,79
4,22
3,76
2,44
•
•
•
•
P.C.B.
1,5 DIA.
PADS
0,71 DIA.
PTH x2
0,20
VERTICAL
MOVEMENT
0,97 DIA.
Ø
0,51 ALIGNMENT PINS
1,63 LONG, x2
See page 130 for Insulator Details
effects of unevenly dispensed solder paste
Two corner alignment pins (power & ground
positions) permit manual placement
Hi-Rel, 4-finger BeCu #30 contact is rated at
3 amps. See page 253 for details
Series 113 uses MM #1334 and #1434 pins. See
pages 162 and 171
Insulators are high temperature thermoplastic,
suitable for all soldering operations
For Electrical, Mechanical and Environmental
Data, see page 264 for details
Total number
of pins
A
B
2,54
ALIGNMENT PINS
C
Quantity
per tube
ORDERING INFORMATION
113-XX-210-41-117000
113-XX-304-41-117000
113-XX-306-41-117000
113-XX-308-41-117000
113-XX-310-41-117000
113-XX-314-41-117000
113-XX-316-41-117000
113-XX-318-41-117000
113-XX-320-41-117000
113-XX-322-41-117000
113-XX-324-41-117000
113-XX-328-41-117000
113-XX-420-41-117000
113-XX-422-41-117000
113-XX-424-41-117000
113-XX-428-41-117000
113-XX-432-41-117000
A
12,6
5,0
7,6
10,1
12,6
17,7
20,3
22,8
25,3
27,8
30,4
35,5
25,4
27,8
30,4
35,5
40,6
30,4
35,5
40,6
45,7
50,8
53,3
60,9
63,5
66,0
63,5
66,0
81,2
B
5,08
7,62
7,62
7,62
7,62
7,62
7,62
7,62
7,62
7,62
7,62
7,62
10,16
10,16
10,16
10,16
10,16
15,24
15,24
15,24
15,24
15,24
15,24
15,24
15,24
15,24
22,86
22,86
22,86
C
7,6
10,1
10,1
10,1
10,1
10,1
10,1
10,1
10,1
10,1
10,1
10,1
12,7
12,7
12,7
12,7
12,7
17,7
17,7
17,7
17,7
17,7
17,7
17,7
17,7
17,7
25,3
25,3
25,3
10
4
6
8
10
14
16
18
20
22
24
28
20
22
24
28
32
24
28
32
36
40
42
48
50
52
50
52
64
41
100
67
50
40
28
25
22
20
18
16
14
20
18
16
14
12
16
14
12
11
10
9
8
8
7
8
7
6
XX=Plating Code
See Below
93
113-XX-950-41-117000
113-XX-952-41-117000
113-XX-964-41-117000
5,08μm
Sn/Pb
0,25μm
Au
2011/65/EU
RoHS - 2
SPECIFY PLATING CODE XX =
Sleeve
(Pin)
Contact
(Clip)
43
5,08μm
Sn
0,25μm
Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 107 | IC SOCKETS / TO SOCKETS
113-XX-624-41-117000
113-XX-628-41-117000
113-XX-632-41-117000
113-XX-636-41-117000
113-XX-640-41-117000
113-XX-642-41-117000
113-XX-648-41-117000
113-XX-650-41-117000
113-XX-652-41-117000
