Amphenol
Miniature Box Interconnects
G810
Materials
Housing
Contacts
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– 1A
– 250 VAC/rms 60Hz
2.54mm Straight SMT Pin Headers
Straight SMT Header
This series was designed to offer both Board to Board (B2B)and Board to Wire (B2W) solutions.
The headers can be cut to size and are modular.
Contact Finish/Durability
Gold Flash
5µ” Gold
15µ” Gold
30µ” Gold
– 75 cycles
– 80 cycles
– 150 cycles
– 250 cycles
– G-19
– G-20/21/22
– G-25
– G-23
Electrical
Current
Voltage
Single Row
Mating Half
Jumpers
B2B Rec.
Ribbon cable Rec.
B2W Rec.
Variations
►
Various Post, Solder Tail and Insulator
Part Number System:
G810 X XX X X X
2.54mm Pin Header
Surface Mount Type
CONNECTOR STYLE
1: Single row
2: Double row
NUMBER OF POSITIONS
02 to 36: Single row
04 to 72: Double row
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
Dual Row
MOUNTING STYLE
1: Standard (w/o Locating Pegs)
2: With Locating Pegs (DIL only)
CONTACT FINISH
1: Gold Flash
2: 15µ” Gold
3: 30µ” Gold
4: 100µ” Tin/Lead
Dimensions (mm)
A
B
50.80
48.26
53.34
50.80
55.88
53.34
58.42
55.88
60.96
58.42
63.50
60.96
66.04
63.50
68.58
66.04
71.12
68.58
73.66
71.12
76.20
73.66
78.74
76.20
81.28
78.74
83.82
81.28
86.36
83.82
88.90
86.36
91.44
88.90
No. of
Positions
PNS-810 Rev. A
HEAD-G8101XX1-13 Rev. A/HEAD-G8102XX2-13 Rev. A
No. of
Positions
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Single Row (SIL)
Dimensions (mm)
No. of
Positions
A
B
5.08
2.54
20
7.62
5.08
21
10.16
7.62
22
12.70
10.16
23
15.24
12.70
24
17.78
15.24
25
20.32
17.78
26
22.86
20.32
27
25.40
22.86
28
27.94
25.40
29
30.48
27.94
30
33.02
30.48
31
35.56
33.02
32
38.10
35.56
33
40.64
38.10
34
43.18
40.46
35
45.72
43.18
36
48.26
45.72
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
Double Row (DIL)
Dimensions (mm)
No. of
Positions
A
B
C
5.08
2.54
40
7.62
5.08
2.54
42
10.16
7.62
5.08
44
12.70
10.16
7.62
46
15.24
12.70
10.16
48
17.78
15.24
12.70
50
20.32
17.78
15.24
52
22.86
20.32
17.78
54
25.40
22.86
20.32
56
27.94
25.40
22.86
58
30.48
27.94
25.40
60
33.02
30.48
27.94
62
35.56
33.02
30.48
64
38.10
35.56
33.02
66
40.64
38.10
35.56
68
43.18
40.46
38.10
70
45.72
43.18
40.46
72
48.26
45.72
43.18
Dimensions (mm)
A
B
C
50.80
48.26
45.72
53.34
50.80
48.26
55.88
53.34
50.80
58.42
55.88
53.34
60.96
58.42
55.88
63.50
60.96
58.42
66.04
63.50
60.96
68.58
66.04
63.50
71.12
68.58
66.04
73.66
71.12
68.58
76.20
73.66
71.12
78.74
76.20
73.66
81.28
78.74
76.20
83.82
81.28
78.74
86.36
83.82
81.28
88.90
86.36
83.82
91.44
88.90
86.36
G890
Materials
Mini Jumpers 2.54mm Pitch
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– Full Gold Flash
– 1A
– 250 VAC/rms 60Hz
– 75 cycles
Housing
Contacts
Contact Finish
Electrical
Current
Voltage
Durability
Full Gold Flash
Mating Half
Pin Header 2.54mm – G-17/18/19/20
Part Number:
G89011020020
G89011030020
G89011021020
G89011031020
G89011022020
G89011032020
AMTA
Type
Open
Closed
Open
Closed
Open
Closed
Colour
Black
Blue
Yellow
Suffix may be added
to Part Number.
This Suffix is for
Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
Dimensions in mm
PNS-890 Rev. A/OTHER-G8901102X-29 Rev. B/OTHER-G8901103X02X-29 Rev. B
G-19
