NPN SILICON PLANAR MEDIUM POWER
HIGH GAIN TRANSISTOR
ISSUE 3 JANUARY 1995
FEATURES
* V
CEO
=120V
* 3 Amp continuous Current
* 6 Amp pulse Current
* Very Low Saturation Voltage
APPLICATIONS
* Automotive Switching Circuit
* Audio Driver Stages
ZTX1055A
C
B
E
E-Line
TO92 Compatible
ABSOLUTE MAXIMUM RATINGS.
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Peak Pulse Current
Continuous Collector Current
Base Current
Power Dissipation at T
amb
=25°C
Operating and Storage Temperature
Range
SYMBOL
V
CBO
V
CEO
V
EBO
I
CM
I
C
I
B
P
tot
T
j
:T
stg
VALUE
175
120
5
6
3
500
1
-55 to +200
UNIT
V
V
V
A
A
mA
W
°C
ZTX1055A
ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated).
PARAMETER
Collector-Base
Breakdown Voltage
Collector-Emitter
Breakdown Voltage
Collector-Emitter
Breakdown Voltage
Collector-Emitter
Breakdown Voltage
SYMBOL
V
(BR)CBO
V
CES
V
CEO
V
CEV
MIN.
175
175
120
175
5
TYP.
280
280
150
280
8.8
0.3
0.3
0.3
22
120
220
950
810
275
300
50
400
450
110
15
130
17
90
2400
30
10
10
10
50
160
310
1000
900
MAX.
UNIT
V
V
V
V
V
nA
nA
nA
mV
mV
mV
mV
mV
CONDITIONS.
I
C
=100µA
IC=100µA
IC=10mA
IC=100µA, V
EB
=1V
I
E
=100µA
V
CB
=130V
V
EB
=4V
VCES=130V
I
C
=0.1A, I
B
=5mA*
I
C
=1A, I
B
=20mA*
I
C
=3A, I
B
=150mA*
I
C
=3A, I
B
=150mA*
IC=3A, V
CE
=10V*
I
C
=10mA, V
CE
=10V*
I
C
=1A, V
CE
=10V*
I
C
=3A, V
CE
=10V*
I
C
=6A, V
CE
=10V*
MHz
pF
ns
ns
I
C
=50mA, V
CE
=10V
f=100MHz
V
CB
=10V, f=1MHz
I
C
=1A, I
B
=10mA, V
CC
=50V
I
C
=1A, I
B
=±10mA,
V
CC
=50V
Emitter-Base Breakdown V
(BR)EBO
Voltage
Collector Cut-Off Current
Emitter Cut-Off Current
Collector Emitter Cut-Off
Current
Collector-Emitter
Saturation Voltage
Base-Emitter
Saturation Voltage
Base-Emitter Turn-On
Voltage
Static Forward Current
Transfer Ratio
I
CBO
I
EBO
I
CES
V
CE(sat)
V
BE(sat)
V
BE(on)
h
FE
1200
Transition Frequency
Output Capacitance
Switching Times
f
T
C
obo
t
on
t
off
*Measured under pulsed conditions. Pulse width=300
µ
s. Duty cycle
≤
2%
ZTX1055A
180
1.0
D=1(D.C)
t1
160
140
Max Power Dissipation - (Watts)
120
100
tp
D=t1
tp
0.75
Am
t
en
bi
D=0.5
m
te
0.50
80
ra
pe
D=0.2
60
D=0.1
D=0.05
re
tu
40
0.25
20
Single Pulse
0
0.1ms
1ms
10ms
100ms
1s
10s
100s
-40
0
40
80
120
160
200
Pulse Width
T -Temperature
(°C)
Transient Thermal Resistance
SPICE PARAMETERS
*ZETEX ZTX1055A Spice model Last revision 25/1/95
Derating curve
*
.MODEL ZTX1055A NPN IS=1.60E-12 NF=1.0 BF=500 IKF=4.0 VAF=120
+
+
+
+
*
ISE=4.0E-13 NE=1.4 NR=1.0 BR=80 IKR=2.5 VAR=15
ISC=5.0E-10 NC=1.7 RB=0.1 RE=0.040 RC=0.030
CJC=63.3E-12 CJE=512.6E-12 MJC=0.439 MJE=0.373
VJC=0.511 VJE=0.800 TF=700E-12 TR=110E-9
The copyright in this model and the design embodied belong to Zetex PLC (Zetex). It is supplied
free of charge by Zetex for the purpose of research and design and may be used or copied intact
(including this notice) for that purpose only. All other rights are reserved. The model is believed
accurate but no condition or warranty as to its merchantability or fitness for purpose is given and
no liability in respect of any use is accepted by Zetex PLC, its distributors or agents.
©
1995 ZETEX PLC
