Series 513 LO-PRO
®
file Collet
Sockets with Solder Tail Pins
FEATURES:
• LO-PRO
®
file Collet Sockets are available with solder tail or wire wrap
pins. Consult Data Sheet No. 12012 for wire wrap pins.
• Choose from several size and plating options.
SPECIFICATIONS:
• Body material is black UL 94V-0 Glass-filled 4/6 Nylon.
• Pin body is Brass Alloy 360 1/2 hard per UNS C36000 ASTM-B16-00.
• Pin body plating is either 10μ [.25μm] min. Gold per MIL-G-45204 or
200μ [5.08μm] min. 93/7 Tin/Lead per ASTM B545 or 200μ [5.08μm]
min. Tin per ASTM B545 Type 1 over 100μ [2.54μm] min. Nickel per
SAE-AMS-QQ-N-290.
• 4-fingered collet contact is Beryllium Copper Alloy per UNS C17200
ASTM-B194-01.
• Contact plating is either 200μ [5.08μm] min. 93/7 Tin/Lead per ASTM
B545 or 200μ [5.08μm] min Tin per ASTM B545 Type 1 or 10μ [.25μm]
Gold per MIL-G-45204 over 50μ min. [1.27μm] Nickel per SAE-AMS-
Note: Aries specializes in custom design and production. In addition to the
standard products shown on this page, special materials, platings, sizes, and
QQ-N-290. Heavy 30μ [.76μm] Gold Plating also available.
configurations can be furnished, depending on quantities. Aries reserves the
• Contact current rating=3 Amps.
right to change product specifications without notice.
• Insertion Force=180 grams/pin; Withdrawal Force=90 grams/pin; Normal
ORDERING INFORMATION
Force=140 grams/pin; based on a .018 [.46] dia. test lead.
• Operating temperature=221°F [105°C] Tin & Tin/Lead plating
XX-X513-1XXX XX
No. of pins
=257°F [125°C] Gold plating.
(see table)
• Accepts leads .015-.025 [.38-.64] in diameter,
Optional plating suffix:
Row-to-row spacing:
.100-.146 [2.54-3.71] long.
H=Heavy Gold on collet
2: “Y”=.200 [5.08]
MOUNTING CONSIDERATIONS:
T=Tin collet/Tin shell
*
: “Y”=.300 [7.62]
•Suggested PCB hole size=.030 ± .002 [.76 ± .05] dia.
TL=Tin/Lead Collet/
A
LL DIMENSIONS
:
INCHES
[
MILLIMETERS
]
“W”=NO. OF PINS PER ROW X .100 [2.54]
“X”=(NO. OF PINS PER ROW - 1) X .100 [2.54]
4: “Y”=.400 [10.16]
6: “Y”=.600 [15.24]
9: “Y”=.900 [22.86]
Series:
Tin/Lead Shell
Plating:
0=Gold collet/Tin shell
0TL=Gold collet/Tin/Lead
shell
1=Gold collet/Gold shell
All tolerances ± .005 [.13]
unless otherwise specified
SOLDER TAIL PIN
*use P/N xx-513-1xxx when
ordering .300 ctr socket
Solder tail pin
Centers “Y”
.200 [5.08]
.300 [7.62]
.400 [10.16]
.600 [15.24]
Dim. “Z”
.300 [5.08]
.400 [10.16
.500 [12.70]
.700 [17.78]
Body Style Available Sizes
A
2 thru 10
C
B
C
C
B
B
2 thru 20
22 thru 40
2 thru 22
2 thru 40
42 thru 48
2 thru 64
.900 [22.86] 1.000 [25.40]
Consult Data Sheet No.
12012 for LO-PRO
®
file
collet sockets with wire
wrap pins.
http://www.arieselec.com • info@arieselec.com
PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED
NORTH AMERICA
Frenchtown, NJ USA
TEL:(908) 996-6841
FAX:(908) 996-3891
abc
EUROPE
TEL: +44 870 240 0249
FAX: +44 871 919 6033
europe@arieselec.com
12011
REV.F
