DUAL-IN-LINE HEADERS
Interconnect
Open Frame
•
Series 142 Pin
Headers have double
ended .018” diameter
pluggable solder tails.
Used to interconnect
PC Boards with
spacings of .210”,
.335”, .585” or .835”.
(MM# 4259-1, -2, -3
or -4 pin). See page
170 for details.
Series 142
•
Total number
of pins
Quantity
per tube
Ordering Information
L=.210
L=.335
142-XX-306-00-592
142-XX-308-00-592
142-XX-314-00-592
142-XX-316-00-592
142-XX-318-00-592
142-XX-320-00-592
142-XX-324-00-592
142-XX-422-00-592
142-XX-624-00-592
142-XX-628-00-592
142-XX-632-00-592
142-XX-640-00-592
A
0.3
0.4
0.7
0.8
0.9
1.0
1.2
1.1
1.2
1.4
1.6
2.0
B
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
C
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
67
50
29
25
22
40
17
14
16
14
12
10
L=.585
142-XX-306-00-593
142-XX-308-00-593
142-XX-314-00-593
142-XX-316-00-593
142-XX-318-00-593
142-XX-320-00-593
142-XX-324-00-593
L=.835
142-XX-306-00-594
142-XX-308-00-594
142-XX-314-00-594
142-XX-316-00-594
142-XX-318-00-594
142-XX-320-00-594
142-XX-324-00-594
6
8
14
16
18
20
24
22
24
28
32
40
142-XX-306-00-591
142-XX-308-00-591
142-XX-314-00-591
142-XX-316-00-591
142-XX-318-00-591
142-XX-320-00-591
142-XX-324-00-591
142-XX-422-00-591
142-XX-624-00-591
142-XX-628-00-591
142-XX-632-00-591
142-XX-640-00-591
142-XX-422-00-593 142-XX-422-00-594
142-XX-624-00-593
142-XX-628-00-593
142-XX-632-00-593
142-XX-640-00-593
142-XX-624-00-594
142-XX-628-00-594
142-XX-632-00-594
142-XX-640-00-594
XX= Plating Code
See Below
For High
Temperature
Insulators
Add ‘100’
To End Of
Part Numbers
SPECIFY PLATING CODE XX=
10
10µ” Au
90
200µ” Sn/Pb
Pin Plating
Mill-Max-Mfg.Corp., P.O. Box 300, 190 Pine Hollow Road, Oyster Bay, NY 11771-0300.Tel: 516-922-6000 Fax: 516-922-9253
44
