PGA Adapters
Table of Models
Pin Grid Array Adapters
.100” (2.54mm) Standard Grid
Description:
Peel-A-Way
®
(KA)
Material: Polyimide Film
Index: -269°C to 400°C (-452°F to 752°F)
Description:
Molded (RCA)
Material: High Temp. Liquid Crystal Polymer
(LCP)
Index: -40°C to 260°C (-40°F to 500°F)
RCA replaces HCA.
Features:
• Screw-machined terminals for
long-term durability
• Mating sockets available
• Custom designs available
Standard Quick-Turn Terminals
Type -79
Peel-A-Way
®
only
.072 Dia.
(1.83)
.125
(3.18)
Type -80
Peel-A-Way
®
only
.072 Dia.
(1.83)
.125
(3.18)
.070
(1.78)
?
.005
(.13)
PC Board
Polyimide
Film
.100
(2.54)
Type -81
Peel-A-Way
®
only
.072 Dia.
(1.83)
.125
(3.18)
.085
(2.16)
.125
(3.18)
.018 Dia.
(.46) Typ. 2
Type -08
.025 Dia.
(.64)
.166
(4.22)
.052
(1.32)
Specifications:
Terminals:
Brass - Copper Alloy
(C36000) ASTM-B-16
Plating:
G - Gold over Nickel
M - Matte Tin over Nickel
T - Tin/Lead over Nickel
Gold per MIL-G-45204
Matte Tin per ASTM545-97
Tin/Lead per MIL-P-81728
Nickel per QQ-N-290
.018 Dia.
(.46) Typ. 2
.125
(3.18)
.030
(.76)
.103
(2.62)
.156
(3.96)
.018 Dia.
(.46)
.125
(3.18)
.018 Dia.
(.46) Typ. 2
Type -68
.018 Dia.
(.46)
.125
(3.18)
.100
(2.54)
Type -43
.018 Dia.
(.46)
.125
(3.18)
Type -185
.018 Dia.
(.46)
.125
(3.18)
Type -42
.018 Dia.
(.46)
.125
(3.18)
.210
(5.33)
.335
(8.51)
.100
(2.54)
.100
(2.54)
.500
(12.70)
.100
(2.54)
.585
(14.86)
.125
(3.18)
.018 Dia.
(.46)
.018 Dia.
(.46)
.125
(3.18)
.018 Dia.
(.46)
.125
(3.18)
.018 Dia.
(.46)
.125
(3.18)
Available Online:
• Hundreds of footprints
• Extraction Tools
• RoHS Qualification Test Report
How To Order
1 RCA 068 - 08
Footprint Dash #
If Applicable
*
Body Type
RoHS Compliant Insulators:
KA - Peel-A-Way
®
M
Terminal Plating
RoHS Compliant:
RCA - New Hi-Temp Molded
Number of Pins
004 to 484
*Footprints available online or
in separate booklet.
G - Gold
M - Matte Tin
T - Tin-Lead
Terminal Type
See options above
Note: Quick-Turn delivery is not available on products with Matte Tin plating.
5 Energy Way, West Warwick, RI 02893 USA
Tel: 800.424.9850 | 401.823.5200
Fax: 401.823.8723
info@advanced.com | www.advanced.com
CAT16-PREVIEW06 Rev. 1/06
Products shown covered by patents issued and/or pending. Specifications subject to change without notice.
12
inch/(mm)
