Series X518 Surface Mount
Single and Dual Row Collet Sockets
FEATURES:
• Surface mount collet sockets are available in single and
dual row.
• ”Break” feature allows strips to be cut to the number of
positions desired.
• Compatible with automatic insertion equipment.
• Side-to-side and end-to-end stackable.
SPECIFICATIONS:
• Body material is black UL 94V-0 Glass-filled 4/6 Nylon.
• Pin body is Brass Alloy 360 1/2 hard per UNS C36000
ASTM-B16-00.
• Pin body plating is either 10
μ
[.25μm] min. Gold per MIL-G-
45204 or 200μ [5.08μm] min. 93/7 Tin/Lead per ASTM
B545 or 200μ [5.08μm] min. Tin per ASTM B545 Type 1
over 100μ [2.54μm] min. Nickel per SAE-AMS-QQ-N-290.
• 4-fingered collet contact is Beryllium Copper Alloy per UNS
Note: Aries specializes in custom design and production. In addition to the
C17200 ASTM-B194-01.
standard products shown on this page, special materials, platings, sizes, and
• Contact plating is 10μ [.25μm] Gold per MIL-G-45204 over
configurations can be furnished, depending on quantities. Aries reserves the
right to change product specifications without notice.
50μ min. [1.27μm] Nickel per SAE-AMS-QQ-N-290.
• Contact current rating=3 Amps.
ORDERING INFORMATION
• Operating temperature=221°F [105°C].
• Insertion Force=180 grams/pin; Withdrawal Force=90
XX-X518-0XXX
grams/pin; Normal Force=140 grams/pin; based on a .018
Plating Options:
[.46] dia. test lead.
No. of pins:
0=Gold collet/Tin
• Accepts leads .015-.025 [.38-.64] in diameter, .100-.125
1-40 single row
shell
[2.54-3.18] long.
MOUNTING CONSIDERATIONS:
2-40 dual row
0TL=Gold collet/
• Suggested PCB pad size=.063 [1.60] dia.
Tin/Lead shell
0=single row
1=dual row
“A”=NO. OF PINS PER ROW X .100 [2.54]
“B”=(NO. OF PINS PER ROW - 1) X .100 [2.54]
Series
A
LL DIMENSIONS
:
0=surface mount
INCHES
[
MILLIMETERS
]
All tolerances ± .005 [.13]
unless otherwise specified
CONTACT DETAIL
http://www.arieselec.com • info@arieselec.com
Bristol, PA USA
TEL: (215) 781-9956
FAX: (215) 781-9845
12019
REV. G
PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED
