F-209
FFSD–20–S–10.00–01–N
FFMD–20–T–02.00–01–N–R
. 050"
(1,27mm)
CABLE STRIPS
FFSD Mates with:
FTS, FTSH, EHF,
SHF, ESHF
FFSD,
FFMD SERIES
OTHER
OPTION
TYPE
STRIP
NO. PINS
PER ROW
END
OPTION
OVERALL
LENGTH
01
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?FFSD
FFSD
–“XX.XX”
–05, –08 –10, –13,
–17,
for other sizes)
–20, –25
(Call
= Assembled Length
Assembled Length
in INCHES (± .130")
2 inches minimum
Insulator Material:
PBT
Contact:
BeCu
Plating:
10µ" (0,25µm) Au over 50µ"
(1,27µm) Ni on contact area;
Sn over 50µ' (1,27µm) Ni
on balance
Wire:
30 AWG
Current Rating:
0.5A
Operating Temp Range:
-40°C to +105°C
Lead Size Accepted:
(0,41mm) .016" SQ
Contact Resistance:
10 mΩ maximum
Insertion Depth:
(2,64mm) .104" to
(3,17mm) .125"
Insertion Force:
(Single contact only)
5oz (1,39N) avg.
Withdrawal Force:
(Single contact only)
3oz (0,83N) avg.
RoHS Compliant:
Yes
Note:
This Series is
non-standard, non-returnable.
–N
= Notch
Polarization
(FFSD only)
–S
= Single End
–D
= Double End
–T
= (FFMD only)
Transfer End
Leave blank
for –S and –D
End Options.
For –T End Option
Specify “–N”
(Socket has
notch polarization)
(FFMD only)
Reverse
Daisy
–RW
= Wiring
–D “XX”
= Chain
2"
min.
–R
= Reverse
Requires –DXX
3
Outside
–O
= Reverse
Strain
–SR
= Relief
No. of positions x
(1,27) .050 + (8,00) .315
“XX”
±
1/8"
01
Middle
–M
= Reverse
4" minimum
02
Requires –DXX
Not available with –S,
–O, –M, –R or –DXX
Mates with:
FLE, SFMC
Blue or black wire
opposite position #1.
1
2
Requires –DXX
3
3
SPECIFICATIONS
For complete specifications
see www.samtec.com?FFMD
FFMD
FFSD
= Socket Strip
(1,90) .075
01
FFMD
= Terminal Strip
01
Insulator Material:
Black Glass Filled
Polyester
Terminal:
BeCu
Plating:
Sn over 50µ" (1,27µm) Ni
Wire:
30 AWG
Current Rating:
0.5A
Operating Temp Range:
-40°C to +105°C
RoHS Compliant:
Yes
(1,02)
.040
No. of positions x
(1,27) .050 + (4,19) .165
(3,05)
.120
No. of positions x
.050 (1,27) + .165 (4,19)
(3,05)
.120
(5,08)
.200
(5,08)
.200
(1,27)
.050
(3,07)
.121
(0,41) .016 SQ
(1,27)
.050
Note:
This Series is
non-standard, non-returnable.
WWW.SAMTEC.COM
