4012 COUPLED INDUCTORS
High-ReliabilityCoupledInductors
ML416PJD
■
Only 1.1 mm high and 4 mm square
■
Ideal for use in flyback, multi-output buck and SEPIC
applications.
■
High inductance, high efficiency and excellent current
handling
■
Can also be used as two single inductors connected in
series or parallel or as a common mode choke.
+
D
+
L1
V
IN
C
SW
L2
C
V
OUT
–
–
Typical Flyback Converter
+
C
V
OUT
AUX
L2
+
1
4
D
–
0.155 ±0.003
*
3,94 ±0,076
1
+
SW
D
4
L2
3
V
IN
L1
C
V
OUT
L1
0.155 ±0.003
*
3,94 ±0,076
–
–
2
Typical Buck Converter with auxiliary output
+
L1
V
IN
D
C1
Q
2
3
+
C
V
OUT
C
L2
0.0433 ±0.004
1,10 ±0,10
Suggested
Land Pattern
1
4
–
45°
typ
0.174
4,40
3
Typical SEPIC schematic
–
0.103 0.049
2,6
1,2
2
0.031
0,78
Core material
Ferrite
+
Core and winding loss
Go to online calculator
L2
C1
Weight
60 – 81 mg
Q
D
C
V
IN
L1
Terminations
Silver-palladium-platinum-glass frit.
+
C
V
OUT
Ambient temperature
–55°C to +105°C with
Irms
current
Storage temperature
Component: –55°C to +155°C.
Tape and reel packaging: –55°C to +80°C
Winding to winding isolation
100 V
0.060
1,52
*
Dimensions are of the case not including
termination. For maximum overall
dimensions including the termination,
add 0.005 in / 0,13 mm
Dimensions are in
inches
mm
0.049
1,2
0.103
2,6
0.174
4,40
–
Maximum part temperature
+155°C (ambient + temp rise)
Typical Zeta schematic
–
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
1000/7″ reel
Plastic tape: 12 mm wide, 0.25 mm thick, 8 mm pocket spacing,
1.32 mm pocket depth
Recommended pick and place nozzle
OD: 4 mm; ID:
≤
2 mm
®
Document ML580-1 Revised 05/22/17
1102 Silver Lake Road
Cary, IL 60013
Phone 800-981-0363
Fax 847-639-1508
Email cps@coilcraft.com
www.coilcraft-cps.com
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specifications subject to change without notice.
Please check our web site for latest information.
© Coilcraft, Inc. 2017
4012 COUPLED INDUCTORS
ML416PJD Series (4012)
Part number
1
ML416PJD331NLZ
ML416PJD561NLZ
ML416PJD821NLZ
ML416PJD152NLZ
ML416PJD222NLZ
ML416PJD332NLZ
ML416PJD472MLZ
ML416PJD562MLZ
ML416PJD682MLZ
ML416PJD822MLZ
ML416PJD103MLZ
ML416PJD153MLZ
ML416PJD223MLZ
ML416PJD333MLZ
ML416PJD473MLZ
ML416PJD683MLZ
ML416PJD823MLZ
ML416PJD104MLZ
ML416PJD124MLZ
ML416PJD154MLZ
ML416PJD184MLZ
ML416PJD224MLZ
ML416PJD334MLZ
Inductance
(µH)
2
DCR max SRF typ
(Ohms)
(MHz)
3
4
Coupling
coefficient
typ
0.94
0.95
0.97
0.97
0.98
0.98
0.98
0.99
0.99
0.99
0.99
0.99
0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
>0.99
Leakage
L typ
5
(µH)
0.06
0.08
0.09
0.11
0.14
0.16
0.18
0.20
0.22
0.24
0.26
0.30
0.34
0.41
0.51
0.66
0.75
0.86
0.98
1.19
1.40
1.66
2.45
10%
drop
5.2
3.7
3.2
2.50
2.30
1.80
1.60
1.50
1.20
1.10
0.98
0.90
0.70
0.37
0.33
0.27
0.27
0.22
0.21
0.18
0.16
0.15
0.13
Isat
(A)
6
20%
30%
drop
drop
5.4
3.8
3.3
2.81
2.40
1.90
1.70
1.60
1.52
1.20
1.00
0.92
0.82
0.57
0.39
0.36
0.27
0.28
0.26
0.26
0.21
0.16
0.16
5.6
3.9
3.4
2.91
2.50
2.00
1.80
1.60
1.63
1.30
1.10
0.94
0.84
0.58
0.40
0.37
0.29
0.29
0.27
0.27
0.23
0.17
0.16
Irms
(A)
both
one
windings
7
winding
8
2.13
1.48
1.38
1.01
0.90
0.77
0.62
0.55
0.60
0.56
0.50
0.41
0.34
0.32
0.27
0.24
0.23
0.20
0.19
0.17
0.15
0.13
0.11
3.01
2.09
1.95
1.43
1.27
1.09
0.87
0.78
0.85
0.80
0.71
0.58
0.48
0.46
0.39
0.34
0.32
0.28
0.26
0.23
0.21
0.18
0.15
0.33 ±30%
0.56 ±30%
0.82 ±30%
1.5 ±30%
2.2 ±30%
3.3 ±30%
4.7 ±20%
5.6 ±20%
6.8 ±20%
8.2 ±20%
10 ±20%
15 ±20%
22 ±20%
33 ±20%
47 ±20%
68 ±20%
82 ±20%
100 ±20%
120 ±20%
150 ±20%
180 ±20%
220 ±20%
330 ±20%
0.042
0.087
0.100
0.185
0.235
0.320
0.500
0.620
0.530
0.600
0.750
1.13
1.63
1.83
2.52
3.23
3.66
4.75
5.54
6.90
8.75
11.24
17.00
255
185
130
86
70
48
39
32
31
29
25
21
15
12
8.8
7.8
7.3
6.1
5.3
4.6
4.1
3.3
2.8
1. When ordering, please specify
termination
and
testing
codes:
ML416PJD334MLZ
Termination: L
= Silver-palladium-platinum-glass frit.
R
= Matte tin over nickel over silver.
Testing:
Z
= Unscreened
H
= Group A screening per Coilcraft CP-SA-10001
T
= Screening per MIL-STD-981
U
= Screening per EEE-INST-002
F
= Screening per ESCC 3201
All screening performed to the document’s latest revision
Custom screening also available
Coupled Inductor Core and Winding Loss Calculator
This web-based utility allows you to enter frequency, peak-to-peak
(ripple) current, and
Irms
current to predict temperature rise and
overall losses, including core loss.
Go to online calculator.
2. Inductance shown for each winding, measured at 100 kHz, 0.1 Vrms,
0 Adc on an Agilent/HP 4284A LCR meter or equivalent. When leads
are connected in parallel, inductance is the same value. When leads are
connected in series, inductance is four times the value.
3. DCR is for each winding. When leads are connected in parallel, DCR
is half the value. When leads are connected in series, DCR is twice the
value.
4. SRF measured using an Agilent/HP 4191A or equivalent. When leads
are connected in parallel, SRF is the same value.
5. Leakage Inductance is for L1 and is measured with L2 shorted.
6. DC current, at which the inductance drops the specified amount from its
value without current. It is the sum of the current flowing in both wind-
ings.
7. Equal current when applied to each winding simultaneously that causes
a 40°C temperature rise from 25°C ambient.
Calculate temperature rise.
8. Maximum current when applied to one winding that causes a 40°C
temperature rise from 25°C ambient. This information is for reference
only and does not represent absolute maximum ratings.
Calculate temperature rise.
9. Electrical specifications at 25°C.
Refer to Doc 639 “Selecting Coupled Inductors for SEPIC Applications.”
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
