RF SURFACE MOUNT
SMRF1812S
SMRF1812SLF*
Molded Shielded Inductor
RECOMMENDED
FOOT PRINT
0.165/0.189
(4.20/4.80)
0.114/0.138
(2.90/3.50)
OVER TRMINAL
PART
NUMBER
L
µH
Q
MIN
0.059
(1.50)
0.177
(4.50)
0.110
(2.80)
0.114/0.138
(2.90/3.50)
0.118/0.134
(3.00/3.40)
0.045/0.075 (1.14/1.91) WIDE
0.016/0.031 (0.40/0.80) DEEP
in. (mm)
NOTES:
Operating Temperature Range:
-55°C to +125°C
Current Rating
is based on a 35°C temperature
rise at an ambient temperature of 90°C
Saturation Current
is the approximate value that will
reduce the initial inductance by 5%
Weight Max:
0.15 grams
Marking:
GEC; SXXX (dash #)
GEC
010
Epoxy-encapsulated for environmental protection and
superior strength to withstand all types of reflow
soldering
When ordering, specify
tolerance
&
termination:
Tolerance:
SMRF1812S-100KLF
M
= 20%,
K
= 10%,
J
= 5%
SMRF1812S-100K
0.10
SMRF1812S-120K
0.12
SMRF1812S-150K
0.15
SMRF1812S-180K
0.18
SMRF1812S-220K
0.22
SMRF1812S-270K
0.27
SMRF1812S-330K
0.33
SMRF1812S-390K
0.39
SMRF1812S-470K
0.47
SMRF1812S-560K
0.56
SMRF1812S-680K
0.68
SMRF1812S-820K
0.82
SMRF1812S-101J
1.0
SMRF1812S-121J
1.2
SMRF1812S-151J
1.5
SMRF1812S-181J
1.8
SMRF1812S-221J
2.2
SMRF1812S-271J
2.7
SMRF1812S-331J
3.3
SMRF1812S-391J
3.9
SMRF1812S-471J
4.7
SMRF1812S-561J
5.6
SMRF1812S-681J
6.8
SMRF1812S-821J
8.2
SMRF1812S-102J
10
SMRF1812S-122J
12
SMRF1812S-152J
15
SMRF1812S-182J
18
SMRF1812S-222J
22
SMRF1812S-272J
27
SMRF1812S-332J
33
SMRF1812S-392J
39
SMRF1812S-472J
47
SMRF1812S-562J
56
SMRF1812S-682J
68
SMRF1812S-822J
82
SMRF1812S-103J
100
SMRF1812S-123J
120
SMRF1812S-153J
150
SMRF1812S-183J
180
SMRF1812S-223J
220
SMRF1812S-273J
270
SMRF1812S-333J
330
SMRF1812S-393J
390
SMRF1812S-473J
470
SMRF1812S-563J
560
SMRF1812S-683J
680
SMRF1812S-823J
820
SMRF1812S-104J 1000
TEST
SRF
FREQ
MIN
MHz
MHz
FERRITE CORE
50
25
460
50
25
400
50
25
390
50
25
350
50
25
310
50
25
280
40
25
240
40
25
215
40
25
205
40
25
185
40
25
166
40
25
155
40
7.9
160
40
7.9
112
40
7.9
65
40
7.9
60
40
7.9
55
40
7.9
50
40
7.9
45
40
7.9
40
40
7.9
35
40
7.9
30
40
7.9
28
40
7.9
25
50
2.5
23
50
2.5
20
50
2.5
18
50
2.5
15
50
2.5
14
50
2.5
13
50
2.5
12
50
2.5
11
50
2.5
9
50
2.5
8
50
2.5
7.6
50
2.5
7.2
40
0.79
7.0
40
0.79
6.0
40
0.79
5.0
40
0.79
4.5
40
0.79
4.2
40
0.79
4.0
40
0.79
3.7
40
0.79
3.5
40
0.79
3.3
40
0.79
2.8
40
0.79
2.6
40
0.79
2.2
40
0.79
2.0
DCR
MAX
0.052
0.060
0.060
0.072
0.078
0.094
0.101
0.109
0.143
0.151
0.160
0.178
0.143
0.151
0.178
0.182
0.208
0.237
0.264
0.282
0.312
0.356
0.394
0.430
0.520
0.585
0.858
0.962
1.300
1.560
2.210
2.340
2.600
2.860
3.308
3.600
3.660
4.000
4.710
5.100
7.500
8.390
9.690
12.0
13.5
17.8
19.3
25.1
27.7
Ω
CURRENT
INC I
RATING
mA DC
mA DC
1959
1824
1824
1665
1600
1457
1406
1353
1182
1150
1117
1059
1182
1150
1059
1047
980
918
870
841
800
749
712
681
620
584
482
456
392
358
301
292
277
264
243
235
234
223
206
198
164
154
144
129
122
106
102
89
85
2250
2000
1800
1636
1500
1385
1286
1200
1059
947
900
750
1236
1164
989
942
824
761
682
638
582
521
471
430
342
306
278
254
228
207
181
174
159
146
133
122
105
95
85
78
70
64
57
53
48
47
45
41
37
Termination: LF
= RoHS compliant tin-silver copper
over copper
Custom designs are available to meet your specific
requirements; please contact factory
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
Gowanda Electronics is an Affiliate of
(Table shows lowest standard tolerance option)
*Optional tolerances are available; contact factory
2200
8 mm
12 mm
13 in.
One Magnetics Pkwy, Gowanda, NY 14070
(f ) 716-532-2702
sales@gowanda.com
REV:
ISSUE
06182019
(t) 716-532-2234
www.GowandaComponentsGroup.com
www.gowanda.com
RF SURFACE MOUNT
SMRF1812S
SMRF1812SLF*
Molded Shielded Inductor
90
80
70
60
50
Q VS. FREQUENCY
SMRF1812 SERIES
1.0 µH
1000 µH
0.33 µH
0.068 µH
10 µH
Q
40
30
20
10
0
0.1
1
10
100
Frequency in MHz
1000
