Differential Mode Inductors
Differential Mode Inductors
Switchmode/high frequency
::
D e s c r i p t i o n
Triad toroidal inductors are specifically designed to minimize transients. These devices store energy, and
therefore, condition the output signal by leveling out the current waveform providing a more stable current
supply. Generally used in high frequency circuits, our standardized design provides an economical solution in
differential mode applications or as an output inductor.
::
T o r o d i a l I n d u c t o r s
Section
Type
No.
FIT44-1
FIT44-2
FIT44-3
FIT44-4
FIT50-1
FIT50-2
FIT50-3
FIT50-4
FIT50-5
FIT50-6
FIT50-7
FIT68-1
FIT68-2
FIT68-3
FIT68-4
FIT68-5
FIT68-6
FIT68-7
FIT80-1
FIT80-2
FIT80-3
FIT80-4
FIT80-5
FIT80-6
FIT106-1
FIT106-2
FIT106-3
FIT106-4
FIT106-5
FIT106-6
Min. Inductance (µH)
No Bias
At Bias
18.85
14.75
12.30
8.06
47.40
35.48
27.16
21.65
16.76
12.50
8.87
89.50
71.10
54.81
43.30
33.16
24.31
18.65
128.00
107.50
80.75
65.04
47.80
38.70
253.00
197.00
154.00
116.00
94.50
70.05
12.72
9.82
7.75
5.22
29.00
23.77
16.13
12.27
9.50
6.75
4.80
57.99
41.59
33.05
26.63
18.79
13.56
10.23
74.04
58.05
42.00
31.60
22.79
18.11
153.00
113.00
84.00
61.90
48.00
35.30
Rated
DCAmps
2.8
3.4
4.0
4.8
2.8
3.4
4.0
4.8
5.7
6.8
8.1
2.8
3.4
4.0
4.8
5.7
6.8
8.1
4.0
4.8
5.7
6.8
8.1
9.7
4.0
4.8
5.7
6.8
8.1
9.7
Max.
DCR (mOhm)
44.8
30.7
23.4
15.9
78.9
57.8
40.1
29.2
20.0
14.0
11.0
108.0
86.1
59.9
42.4
28.8
20.2
14.8
95.2
67.9
44.8
32.8
22.5
17.0
139.0
106.0
74.0
48.5
39.1
24.0
A
0.625
B
0.350
Dimensions
C
0.700
D
0.250
E
0.020
0.022
0.025
0.028
0.020
0.022
0.025
0.028
0.032
0.036
0.040
0.020
0.023
0.026
0.028
0.032
0.036
0.040
0.026
0.029
0.032
0.036
0.040
0.045
0.026
0.029
0.032
0.036
0.040
0.045
Wt.
Lbs.
.008
A
B
0.700
0.475
0.750
0.300
.012
C
0.875
0.475
0.950
0.300
.026
D
0.975
0.625
1.100
0.450
.045
E
1.300
0.725
1.400
0.500
.090
A FIT-KIT is available which includes one of each of the above listed components.
::
O u t l i n e D i m e n s i o n s
Te c h n i c a l N o t e s
1.
Nominal inductance values are typically 10%
higher than minimal rating.
2.
Biased inductance measured at rated DC amps.
3.
Operation at rated current yields approximately
40ºC temperature rise over 20ºC ambient.
www.TriadMagnetics.com
|
460 Harley Knox Blvd., Perris, CA 92571
|
Phone 951-277-0757
|
FAX 951-277-2757
