520470-4: DescriptionPHONE CONNECTOR,PCB MNT,6 CONTACTS,SKT,PC TAIL TERMINAL,LATCH; CategoryThe connector The connector; File Size117KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

520470-4 Overview

PHONE CONNECTOR,PCB MNT,6 CONTACTS,SKT,PC TAIL TERMINAL,LATCH

520470-4 Parametric

Parameter Name	Attribute value
Objectid	302499150
Reach Compliance Code	unknown
ECCN code	EAR99
YTEOL	0
Other features	TRAY LOADED
Board mount options	SPLIT BOARD LOCK
body width	0.637 inch
subject depth	0.815 inch
body length	0.525 inch
Body/casing type	RECEPTACLE
Connector type	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	AU ON NI
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
Contact style	TELCOM, MODULAR
Dielectric withstand voltage	1000VAC V
Durability	750 Cycles
Insulation resistance	500000000 Ω
Insulator color	BLACK
insulator material	POLYESTER
Installation option 1	LATCH
Installation option 2	LATCHING
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of ports	1
Plating thickness	50u inch
Rated current (signal)	0.2 A
Guideline	CSA, UL
Terminal length	0.15 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	6

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Modular Jacks & Plugs

Product Feature Selector

> Product Details

520470-4 Product Details

Live Product Chat

Product Photo

PCB Mounted Jacks - Single Port, Multi-port and Stacked

Always ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

520470-4

T E I nternal N umber: 5 2 0 4 7 0 - 4

Product Highlights:

Jack

Single Port C onfiguration

1 x 1 Jack C onfiguration

Jack Type = RJ11

Number of Positions = 6

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

Modular Plugs, Thru-Hole and Surface Mount Jacks, Da...

(PDF, English)

Application Specifications:

Modular Jacks

(PDF, English)

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Jack

Jack Type

= RJ11

Number of Positions

= 6

PC B Mount Angle

= Side Entry (Right Angle)

PC B Mount Style

= Through Hole

PC B Termination Type

= Solder

Shielded

= No

Performance C ategory

= C at 3

Number of C ontacts Loaded = 2

Grounding Options = Without

Panel Stops

= Without

Keyed

= No

Profile

= Standard

C olor

= Black

Latch Style = Standard

PC B Thickness (mm [in]) = 1.57 [0.062]

Mechanical Attachment:

Jack C onfiguration

= 1 x 1

Panel Attachment

= With

Flanged = No

Termination Related Features:

Height (mm [in])

= 16.13 [0.635]

Solder Tail C ontact Plating

= Tin-Lead over Nickel

Body Related Features:

Port C onfiguration = Single

Inverted Jack Face

= No

LED

= Without

PC B Tail Length (mm [in])

= 3.80 [0.150]

Contact Related Features:

C ontact Mating Area Plating Material

= Gold (50)

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing Material = Polyester (PBT)

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant

Lead Free Solder Processes

= Not reviewed for lead free solder

process

RoHS/ELV C ompliance History = Always was ELV compliant

Packaging Related Features:

Packaging Method = Tray

Other:

Brand = AMP

Additional Information:

Product Line Information
