Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
744776012A
SPEICHERDROSSEL WE-PD2
POWER-CHOKE WE-PD2
DATUM / DATE : 2007-01-02
A
Mechanische Abmessungen / dimensions:
A
C
Typ XL
A
B
C
D
E
F
G
9,5 ± 0,3
9,5 ± 0,3
5,5 ± 0,3
2,9 typ
10,0 ref
10,0 ref
2,8 ref
mm
mm
mm
mm
mm
mm
mm
B
marking dot is start winding &
inductance code
B
Elektrische Eigenschaften / electrical properties:
Eigenschaften /
properties
Induktivität /
inductance
Güte Q /
Q factor
DC-Widerstand /
DC-resistance
Nennstrom /
rated current
Eigenres.-Frequenz /
self-res.-fequency
Testbedingungen /
test conditions
1 kHz / 0,25V
7,960 MHz
Wert / value
Einheit / unit
tol.
±20%
D
C
Lötpad
/
soldering spec.:
E
L
Q
R
DC
I
DC
SRF
1,2
µH
0,02
5,50
130,00
Ω
A
MHz
max.
max.
G F
D
Prüfgeräte
/
test equipment:
HP 4274 A
für/for L und/and Q
HP 4274 A
für/for R
DC
und I
DC
E
Testbedingungen
/
test conditions:
Luftfeuchtigkeit / humidity:
Umgebungstemperatur / temperature:
33%
+20°C
F
Werkstoffe & Zulassungen / material & approvals
Basismaterial / base material:
Draht / wire:
Ferrit
class F
G
Eigenschaften / general specifications:
Lagertemperatur / storage temperature: -40°C ~ + 125°C
Betriebstemp. / operating temperature: -40°C ~ +105°C
Freigabe erteilt / general release:
Kunde / customer
...........................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
..................................................................................
...........................................................................
MST
Name
Neugestaltung
Änderung / modification
07-01-02
Geprüft / checked
Kontrolliert / approved
Datum / date
This electronic component has been designed and developed for usage in general electronic equipment. Before incorporating this component into any equipment where higher safety
and reliability is especially required or if there is the possibility of direct damage or injury to human body, for example in the range of aerospace, aviation, nuclear control, submarine,
transportation, (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc, Würth Elektronik eiSos GmbH must be
informed before the design-in stage. In addition, sufficient reliability evaluation checks for safety must be performed on every electronic component which is used in electrical circuits
that require high safety and reliability functions or performance.
Würth Elektronik eiSos GmbH & Co.KG
D-74638 Waldenburg · Max-Eyth-Strasse 1 - 3 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
SEITE 1 VON 1
