SCX114

SMD POWER INDUCTORS

●

Features

Excellent Power Density.

Engineered to Provide High Efficiency through Toroidal Design.

Low EMI Radiation.

Available in a wide Current Range of 0.16 to 5.5ADC.

ELECTRICAL CHARACTERISTICS

PARALLEL

Full Load

Inductance

Current Adc

uH min

0.31

0.43

0.73

1.36

3.37

5.31

6.23

9.62

14.12

17.07

22.27

33.57

43.65

63.64

96.64

130.79

190.05

5.50

5.10

4.50

3.40

2.00

1.80

1.70

1.40

1.00

0.96

0.80

0.70

0.66

0.54

0.44

0.36

0.32

SERIES

DC Resistance

ohms max.

0.009

0.011

0.014

0.018

0.041

0.052

0.057

0.087

0.159

0.177

0.251

0.316

0.373

0.557

0.844

1.208

1.525

Open Circuit

Inductance

uH+/-20%

1.67

2.40

4.28

8.08

18.8

32.33

38.48

60.12

81.83

101.60

129.32

202.07

273.61

396.06

602.87

793.65

1199.46

Full Load

Inductance

uH min

1.25

1.74

2.92

5.44

13.47

21.23

24.94

38.47

56.47

68.29

89.06

134.27

174.61

254.55

386.56

523.16

760.19

Full Load

Current Adc

2.75

2.55

1.70

1.00

0.90

0.85

0.70

0.50

0.48

0.40

0.35

0.33

0.27

0.22

0.18

0.16

DC Resistance

ohms max.

0.040

0.045

0.056

0.070

0.161

0.208

0.227

0.348

0.634

0.708

1.001

1.263

1.490

2.227

3.376

4.831

6.100

Part Number

Open Circuit

Inductance

uH+/-20%

0.47

0.68

1.2

2.2

4.7

8.0

9.6

100

150

200

300

SCX114-R47

SCX114-R68

SCX114-1R2

SCX114-2R2

SCX114-4R7

SCX114-8R0

SCX114-9R6

SCX114-150

SCX114-200

SCX114-250

SCX114-320

SCX114-500

SCX114-680

SCX114-101

SCX114-151

SCX114-201

SCX114-301

NOTES:

(1). Parameters to be tested at 100KHZ, 0.25V ,0VDC and 25℃

Parallel: (1,4-3,2) Series:(1-3) with (2-4) tied.

(2). The DC current that results in a 40℃ temperature rise. Overall unit temperature should not exceed 85℃

(ambient

+ temperature rise).

(3). Hi-pot winding to winding: 300Vdc min.

(4). Turns Ratio:(1-2) : (4-3) 1:1

Click here for

QUANTITY PER REEL & PACKING INFORMATION

Custom versions available upon request.

2011 Signal Transformer –Specification subject to change without notice. 07.11

www.signaltransformer.com

500 Bayview Avenue, Inwood, NY 11096

Toll Free 866-239-5777 • Tel 516-239-5777 • Fax 516-239-7208
