RADIAL DRUM CORE POWER CHOKE
AIRD-02
FEATURES:
• Ferrite core with UL tube
• Wire wound construction
• High current, low DCR
STANDARD SPECIFICATIONS
Pb
RoHS
Compliant
APPLICATIONS:
• Electronic Appliance
• Power Supplies
• TRIAC/SCR Control Circuits
21.0 x ϕ21.0 mm
| | | | | | | | | | | | | | |
Operating Temperature:
-25°C ~
+85°C
Storage Temperature:
-25°C ~
+125°C
Part Number
Units
Symbol
AIRD-02-1R0
AIRD-02-1R2
AIRD-02-1R5
AIRD-02-1R8
AIRD-02-2R2
AIRD-02-2R7
AIRD-02-3R3
AIRD-02-3R9
AIRD-02-4R7
AIRD-02-5R6
AIRD-02-6R8
AIRD-02-8R2
AIRD-02-100
AIRD-02-120
AIRD-02-150
AIRD-02-180
AIRD-02-220
AIRD-02-270
AIRD-02-330
AIRD-02-390
AIRD-02-470
AIRD-02-560
AIRD-02-680
AIRD-02-820
AIRD-02-101
AIRD-02-121
AIRD-02-151
AIRD-02-181
AIRD-02-221
AIRD-02-271
AIRD-02-331
AIRD-02-391
AIRD-02-471
AIRD-02-561
AIRD-02-681
AIRD-02-821
AIRD-02-102
AIRD-02-122
AIRD-02-152
AIRD-02-182
AIRD-02-222
Inductance
μH
L
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
Tolerance
%
K, M
K, M
K, M
K, M
K, M
K, M
K, M
K, M
K, M
K, M
K, M
K, M
K, M
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
DCR (Max)
Ω
DCR
0.003
0.003
0.003
0.003
0.004
0.005
0.005
0.005
0.005
0.006
0.007
0.007
0.009
0.009
0.013
0.018
0.019
0.026
0.029
0.030
0.035
0.039
0.053
0.060
0.080
0.090
0.098
0.110
0.150
0.213
0.305
0.320
0.355
0.388
0.430
0.590
0.818
1.140
1.260
1.390
1.540
Temperature
Rise Current (Max)
A
Irms*
108
108
83
68
68
58
58
50
50
44
39
36
30
27
25
22
21
20
18
17
15
13
12
11
10
9.4
8.6
7.8
7.0
6.3
5.2
4.9
4.5
4.1
3.7
3.4
3.1
2.7
2.4
2.2
2.0
Saturation
Current (Max)
A
Isat*
11.4
11.4
11.4
11.4
11.4
11.4
11.4
11.4
11.4
11.4
11.4
11.4
11.4
11.4
9.0
7.2
7.2
5.5
5.5
5.5
5.5
5.5
4.8
4.8
4.0
4.0
4.0
4.0
2.8
2.0
1.6
1.6
1.6
1.6
1.6
1.3
1.0
0.8
0.8
0.8
0.8
Test Conditions and equipments
Test
frequency: 1KHz, 0.1Vrms
DCR: QuadTech Milliohmmeter
Isat:
10% inductance drops from initial value
Irms: ΔT of 40°C temperature rise max
ABRACON IS
ISO 9001 / QS 9000
ISO 9001:2008
CERTIFIED
Revised: 08.16.11-A
30332 Esperanza, Rancho Santa Margarita, California92688
tel 949-546-8000
|
fax 949-546-8001|
www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
RADIAL DRUM CORE POWER CHOKE
AIRD-02
PART NUMBER IDENTIFICATION
Pb
RoHS
Compliant
21.0 x ϕ21.0 mm
| | | | | | | | | | | | | | |
AIRD-02-
*1.0 ~
8.2µH:
K
and
M
10
~
2200µH:
K
only
Inductance Code
Please refer to the
Electrical Spec
Table
Tolerance
M:
±20%*
K:
±10%*
OUTLINE DIMENSION:
Polyolefin Shrink Tube
0.071 max.
(1.8 max.)
Dimension: inch (mm)
