TTL 5.0V Oscillator
Model: F1100ElF
RoHS compliant / Pb Free
Rev. 9/18/2006
http://www.foxonline.com/need_a_sample.htm
• PART nUMbER SElEcTiOn
Part Number
049LF-Freq-xxxxx
343LF-Freq-xxxxx
060LF-Freq-xxxxx
061LF-Freq-xxxxx
055LF-Freq-xxxxx
465LF-Freq-xxxxx
Learn More - Internet Required
Model
Frequency
Operating
Frequency
Number
Stability
1
Temperature (ºC) Range (MHz)
0 ~ +70
F1100ELF
±100PPM
(STD)
1.000 ~ 100.000
-40 ~ +85
F1100ERLF
±100PPM
1.000 ~ 100.000
±50PPM
0 ~ +70
F1145ELF
1.000 ~ 100.000
±50PPM
-40 ~ +85
F1145ERLF
1.000 ~ 70.000
±25PPM
0 ~ +70
F1144ELF
1.000 ~ 100.000
±25PPM
-40 ~ +85
F1144ERLF
1.000 ~ 70.000
learn more about:
Part Marking Identification
Mechanical Specification
internet required
• ElEcTRicAl cHARAcTERiSTicS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
1.000 ~ 8.000 MHz
8.000+ ~ 24.000 MHz
24.000+ ~ 70.000 MHz
70.000+ ~ 100.000 MHz
Output Symmetry (1.4V Level)
1.000 ~ 8.000 MHz
8.000+ ~ 100.000 MHz
Rise Time (0.5V ~ 2.4V) (T
r
)
1.000 ~ 25.000 MHz
25.000+ ~ 70.000 MHz
70.000+ ~ 100.000 MHz
Fall Time (2.4V ~ 0.5V) (T
f
)
1.000 ~ 25.000 MHz
25.000+ ~ 70.000 MHz
70.000+ ~ 100.000 MHz
Output Voltage
1.000 ~ 25.000 MHz
(V
ol
)
25.000+ ~ 100.000 MHz
1.000 ~ 100.000 MHz
(V
oh
)
Output Current
(I
ol
)
(I
oh
)
Output Load
Start-up Time
(T
s
)
1.000 ~ 3.500 MHz
3.500+ ~ 4.000 MHz
4.000+ ~ 6.000 MHz
6.000+ ~ 20.000 MHz
20.000+ ~ 100.000 MHz
1
MAX
(unless otherwise noted)
1.000 ~ 100.000 MHz
-55ºC ~ +125ºC
5.0V ± 10%
15mA
30mA
70mA
80mA
45% ~ 55%
40% ~ 60%
10 nS
5 nS
4 nS
10 nS
5 nS
4 nS
0.4V
0.5V
2.4V Min
20mA Min
-1.0mA Min
10TTL
20mS
35mS
30mS
20mS
15mS
All dimensions are in millimeters.
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, and vibration.
All specifications subject to change without notice.
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2006 FOX ELECTRONICS | ISO9001:2000 Certified
