MAXQ7667AACM/V+GB

Description
IC mcu-based das 16bit 48-lqfp
CategoryThe embedded processor and controller    Microcontrollers and processors
File Size2MB,10 Pages
ManufacturerMaxim
Websitehttps://www.maximintegrated.com/en.html
Environmental Compliance
Download Datasheet Parametric Compare View All

MAXQ7667AACM/V+GB Overview

IC mcu-based das 16bit 48-lqfp

MAXQ7667AACM/V+GB Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerMaxim
package instructionLFQFP,
Reach Compliance Codecompliant
Has ADCYES
Address bus width
bit size16
maximum clock frequency16 MHz
DAC channelNO
DMA channelNO
External data bus width
JESD-30 codeS-PQFP-G48
length7 mm
Humidity sensitivity level1
Number of I/O lines16
Number of terminals48
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
PWM channelYES
Package body materialPLASTIC/EPOXY
encapsulated codeLFQFP
Package shapeSQUARE
Package formFLATPACK, LOW PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius)NOT SPECIFIED
ROM programmabilityFLASH
Maximum seat height1.6 mm
speed16 MHz
Maximum supply voltage2.75 V
Minimum supply voltage2.25 V
Nominal supply voltage2.5 V
surface mountYES
technologyCMOS
Temperature levelAUTOMOTIVE
Terminal formGULL WING
Terminal pitch0.5 mm
Terminal locationQUAD
Maximum time at peak reflow temperatureNOT SPECIFIED
width7 mm
uPs/uCs/peripheral integrated circuit typeMICROCONTROLLER, RISC
MAXQ7667 Evaluation Kit
Evaluates: MAXQ7667
General Description
The MAXQ7667 evaluation kit (EV kit) demonstrates
distance measurement with the MAXQ7667.
The EV kit includes Windows XP
®
-, Windows
Vista
®
-, and Windows
®
7-compatible software for distance
measurements data acquisition through a USB cable.
Quick Start
Features
Windows XP-, Windows Vista-, and Windows 7-
Compatible Software
USB-PC Connection (Cable Included)
USB Powered (External Power Supply Not Required)
Real-Time Data Acquisition through the USB
Ordering Information
appears at end of data sheet.
The EV kit board is a plug-n-play, ultrasound echo acqui-
sition kit that connects to the PC through a USB cable.
The EV kit produces an ultrasound burst and samples the
echo and sends the information back to the PC. Distance
to multiple objects can be calculated from the echo. The
board does not require external power; it is powered
through the USB. The USB-to-serial driver can be down-
loaded from www.ftdichip.com/Drivers/VCP.htm.
The EV kit is preloaded with default firmware that
communicates with the MAXQ7667 evaluation software.
Software can be installed and run on any Windows-based
system.
ULTRA SOUND
TRANSDUCER
ULTRA SOUND BURST GENERATOR
REF
2.5V
LNA
SIGMA DELTA
ADC
MAXQ7667
POWER-SUPPLY
TEMP-SUPPLY (PTC)
5 CH
MUX
SAR
ADC
MAXQ
MICRO-
CONTROLLER
UART
5.0V
FTDI
Figure 1. MAXQ7667 EV-Kit Block Diagram
Windows, Windows XP, and Windows Vista are regis-
tered trademarks and registered service marks of Microsoft
Corporation.
19-5013; Rev 1; 2/14

MAXQ7667AACM/V+GB Related Products

MAXQ7667AACM/V+GB MAXQ7667EVKIT+ MAXQ7667AACM+
Description IC mcu-based das 16bit 48-lqfp kit eval for max7667 IC MCU 16BIT 32KB FLASH 48LQFP
Is it Rohs certified? conform to - conform to
Maker Maxim - Maxim
package instruction LFQFP, - QFP,
Reach Compliance Code compliant - compliant
Has ADC YES - YES
bit size 16 - 16
maximum clock frequency 16 MHz - 16 MHz
DAC channel NO - NO
DMA channel NO - NO
JESD-30 code S-PQFP-G48 - S-PQFP-G48
length 7 mm - 7 mm
Number of I/O lines 16 - 16
Number of terminals 48 - 48
Maximum operating temperature 125 °C - 125 °C
Minimum operating temperature -40 °C - -40 °C
PWM channel YES - YES
Package body material PLASTIC/EPOXY - PLASTIC/EPOXY
encapsulated code LFQFP - QFP
Package shape SQUARE - SQUARE
Package form FLATPACK, LOW PROFILE, FINE PITCH - FLATPACK
Peak Reflow Temperature (Celsius) NOT SPECIFIED - NOT SPECIFIED
ROM programmability FLASH - FLASH
Maximum seat height 1.6 mm - 1.6 mm
speed 16 MHz - 16 MHz
Maximum supply voltage 2.75 V - 2.75 V
Minimum supply voltage 2.25 V - 2.25 V
Nominal supply voltage 2.5 V - 2.5 V
surface mount YES - YES
technology CMOS - CMOS
Temperature level AUTOMOTIVE - AUTOMOTIVE
Terminal form GULL WING - GULL WING
Terminal pitch 0.5 mm - 0.8 mm
Terminal location QUAD - QUAD
Maximum time at peak reflow temperature NOT SPECIFIED - NOT SPECIFIED
width 7 mm - 7 mm
uPs/uCs/peripheral integrated circuit type MICROCONTROLLER, RISC - MICROCONTROLLER, RISC
