PIP/PHP 8.4
thru
7,500 & 15,000 Watt TVS Module
PIP/PHP 500
TEL:805-498-2111 FAX:805-498-3804
DESCRIPTION
The PIP & PHP series of transient voltage suppression
modules are designed to protect military and
commercial electronic equipment from overvoltages
caused by lightning, power interrupt, inductive load
switching, AC line fluctuations, and NEMP. These
modules find applications in both commercial and
military environments, including telecommunications,
shipboard and aircraft, power distribution, computers,
and power supplies. For military applications, the PHP
module sub-assemblies are metallurgically bonded and
packaged in a hermetically sealed package.
TVS modules are most often used in applications where
discrete TVS diodes do not have high enough surge
handling capabality to suppress large power surges.
FEATURES:
•
•
•
•
•
•
•
•
7500 & 15000 watts Peak Pulse Power
(tp = 10 x 1000µs)
PIP
series designed for industrial applications.
PHP
series designed for aerospace applications.
Bidirectional
Custom voltages available from factory.
MECHANICAL CHARACTERISTICS:
Molded Case
Readily solderable terminals
Marking : Logo, part number, and date code
SCHEMATIC
SCREENING:
100% Screening is available per MIL-S-19500/516. For
ordering use the following suffix:
H1 - Submodule screening
H2 - Submodule & module screening
H3 - Submodule & module screening + Group B & C
MAXIMUM RATINGS
RATING
Peak Pulse Power (tp = 10 x 1000µs)
Operating Temperature
Storage Temperature
SYMBOL
Ppk
Tj
Tstg
VALUE
7500 & 15000
-65 to +150
-65 to +150
UNIT
Watts
°C
°C
ELECTRICAL CHARACTERISTICS @ 25°C
PART
NUMBER
(COMMERCIAL)
AVERAGE RMS
VOLTAGE
VOLTS AC
REVERSE
STAND-OFF
VOLTAGE
V
RWM
REVERSE
LEAKAGE
CURRENT
I
R
MINIMUM
BREAKDOWN
VOLTAGE
V
BR
@ I
T
TEST
CURRENT
I
T
MAXIMUM
CLAMPING
VOLTAGE
Vc @ Ipp
PEAK PULSE
CURRENT
Ipp
tp = 10/1000µs
MAXIMUM
PEAK PULSE
POWER
tp = 10/1000µs
(V)
PIP 8.4
PIP 24
PIP 30
PIP 60
PIP 120
PIP 208
PIP 250
PIP 440
PIP 500
PHP 8.4
PHP 24
PHP 30
PHP 60
PHP 120
PHP 208
PHP 250
PHP 440
PHP 500
8.4
24.0
30.0
60.0
120.0
208.0
250.0
440.0
500.0
8.4
24.0
30.0
60.0
120.0
208.0
250.0
440.0
500.0
(V)
12.0
34.0
42.5
85.0
170.0
295.0
354.0
623.0
708.0
12.0
34.0
42.5
85.0
170.0
295.0
354.0
623.0
708.0
(µA)
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
(V)
14
40
50
100
200
347
418
735
835
14
40
50
100
200
347
418
735
835
(mA)
10
10
1
1
1
1
1
1
1
10
10
1
1
1
1
1
1
1
(V)
22
67
84
167
319
536
652
1138
1292
22
67
84
167
319
536
652
1138
1292
(A)
341
112
90
90
47
28
23
13.2
11.6
341
112
90
90
47
28
23
13.2
11.6
(kw)
7.5
7.5
7.5
15.0
15.0
15.0
15.0
15.0
15.0
7.5
7.5
7.5
15.0
15.0
15.0
15.0
15.0
15.0
MILITARY APPLICATIONS :
PHP series sub-assemblies are packaged in a hermetically sealed case.
COMMERCIAL APPLICATIONS :
PIP series sub-assemblies are packaged in a molded epoxy case.
© 1997 SEMTECH CORP.
652 MITCHELL ROAD NEWBURY PARK CA 91320
