e t B u r n e r
Networking in 1 Day!
Mod5270
10/100 Processor Module
Features
• Complete solution for embedded
applications
• Start writing you application
code immediately, instead of
integrating development tools or
building custom hardware.
• Use as a high-performance
single board computer or as a
network interface processor.
• Network development kit
available with RTOS, TCP/IP,
Web Server, C/C++ Compiler,
IDE, Graphical Debugger,
configuration and deployment
tools.
• Module includes 3 UARTs,
QSPI, I2C, 8 timers, Watchdog
timer, Address bus, Data bus,
GPIO, Interrupts and more.
• Powerful 95MHz 32-bit
Freescale ColdFire 5270
processor with integrated
10/100 Ethernet MAC.
• 2MB SDRAM, 512KB Flash
memory, 64k fast SRAM on
processor, 8k cache.
The Mod5270 processor module is a low cost, high performance single board
computer solution to network-enable both existing and new product designs with
10/100BaseT Ethernet. Based on the Freescale ColdFire 5270 32-bit processors with
integrated 10/100 Ethernet MAC, it has plenty of horsepower for the most demand-
ing applications (rated at 96 MIPS with 100 MHz clock).
Network-Enable Existing Applications:
Add a module to an existing application to network enable the device through
serial ports, GPIO pins, address/data bus, I2C or QSPI.
Network-Enable New Applications
Add a module to an application-specific motherboard, and you have a powerful
processing platform that can function as the control processor for the product, or
as a low cost network interface processor.
Customize to Suit Any Application
TheNetBurner Network Development kit enables you to quickly and easily create
custom applications. NetBurner has a solid reputation for development platforms
to facilitate rapid product development, and the Mod5270 kit is no exception. The
kit includes the hardware platform, TCP/IP Stack, uC/OS Real-time operating
system, Web Server, GNU C/C++ compiler and linker, Integrated Development
Environment (IDE), GDB graphical debugger, end-user device configuration, flash
update utilities, and much more.
Real 32-Bit Performance
Traditionally, companies using 8 and 16-bit platforms find it nearly impossible to
run resource-intensive applications on fast Ethernet connections. The NetBurner
Mod5270 features a full 32-bit architecture, at a price point less than many 8 or 16-
bit devices. The Mod5270 high-performance processing platform provides the
horsepower to handle both 10/100 Ethernet connections and resource-demanding
applications with ease and flexibility.
Specifications
Processor
32-bit Freescale ColdFire 5270 with
integrated 10/100 Ethernet MAC
Network Interface
10/100BaseT with RJ-45 connector
Network Protocols Supported
Complete protocol support included.
See NNDK-MOD5270-KIT datasheet
for details. Includes:
• ARP
• BOOTP
• DHCP
• FTP
• HTTP
• ICMP
• IGMP
• IP
• NTP
• SMTP
• POP3
• PPP
• TCP
• DNS
• UDP
Software Development
• NetBurner Network Development
Kit includes: RTOS, TCP/IP Stack,
Web Server, C/C++ Compiler,
Integrated Development Environ-
ment (IDE), Graphical Debugger,
configuration and deployment tools.
LEDs
• 10/100 Ethernet Speed
• Link/Activity
Physical Characteristics
Dimensions: 2.0” x 2.6”
Mounting Holes: 2 x 0.125” dia
Connectors
Two standard dual row 50-pin 0.1” headers
Power Requirements
500mA @ 3.3V
Environmental
Operating Temperature: 0 - 70°C
Ordering Information
MODULES
Freescale p/n: MOD5270 (single piece)
Freescale p/n: MOD5270BX (quantities greater than 100)
NetBurner p/n: MOD5270-100 (any quantity)
DEVELOPMENT KITS
Freescale p/n: M5270PROMO (binary release)
NetBurner p/n: NNDK-MOD5270-KIT (source code release)
Contact Information
NetBurner, Inc.
5405 Morehouse Drive
San Diego, CA 92121
http://www.netburner.com
858.558.0293 phone
858-558-8549 fax
sales@netburner.com
© 2005 NetBurner, Inc. Specifications are subject to change without notice. Every effort has been made to ensure all information is correct, but
NetBurner, Inc. is not responsible for inadvertant errors. Freescale(tm) and the Freescale logo are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners. (c) Freescale Semiconductor, Inc. 2005
