Product Bulletin HCC240
September 1996
Surface Mount Optically Coupled Isolator
Types HCC240, HCC242, TX, TXV, ESA-XN
Features
•
Surface mountable on ceramic or
printed circuit board
•
Miniature package saves circuit board
area
•
Electrical performance similar to
4N22A and 4N24A
•
Hermetically sealed
•
Screened per MIL-PRF-19500 TX and
TXV equivalent levels or per ESA
5000
(6)
Absolute Maximum Ratings
(T
A
= 25
o
C unless otherwise noted)
Input-to-Output Isolation Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±1.0 kVDC
(1)
Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55
o
C to +125
o
C
Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -65
o
C to +150
o
C
Soldering Temperature (vapor phase reflow for 30 sec.) . . . . . . . . . . . . . . . . . 215
o
C
Soldering Temperature (heated collet for 5 sec.) . . . . . . . . . . . . . . . . . . . . . . . 260
o
C
Input Diode
Forward DC Current (65
o
C below) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 mA
Reverse Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.0 V
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 mW
(2)
Output Phototransistor
Continuous Collector Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 mA
Collector-Emitter Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 V
(3)
Emitter-Collector Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.0 V
(4)
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300 mW
(5)
Notes:
(1) Measured with inputs shorted together and outputs shorted together.
(2) Derate linearly 1.0 mW/
o
C above 65
o
C.
(3) HCC240HV and HCC242HV are available rated at 55 V minimum.
(4) HCC240HV and HCC242HV are available rated at 7.0 V minimim.
(5) Derate linearly 3.0 mW/
o
C above 25
o
C.
(6) Some deviations from ESA 5000 apply. See page 13-4 for details.
Description
The HCC240 and HCC242 are optically
coupled isolators, consisting of a gallium
aluminum arsenide LED and a silicon
phototransistor mounted and coupled in
a miniature surface mount hermetic
leadless chip carrier. The HCC240 and
HCC242 are identical except for the DC
current transfer ratio. Electrical
parameters are similar to the JEDEC
registered 4N22A and 4N24A. These
solid state couplers are ideal for designs
where board space and device weight
are important design considerations.
Typical screening and lot acceptance
tests are provided on page 13-4. The
burn-in condition is V
CE
= 9 V, P
D
= 275
mW, I
F
= 20-50 mA (adjusted to achieve
PD). No HTRB is performed on this
device.
Optek Technology, Inc.
1215 W. Crosby Road
Carrollton, Texas 75006
15-28
(972) 323-2200
Fax (972) 323-2396
Types HCC240, HCC242, TX, TXV, ESA-XN
Electrical Characteristics
(T
A
= 25
o
C unless otherwise noted)
SYMBOL
Input Diode
V
F
PARAMETER
MIN TYP MAX UNITS
0.80
1.00
0.70
1.5
1.7
1.3
100
30
5.0
100
100
V
V
V
µA
V
V
nA
µA
mA
6.0
mA
mA
mA
mA
15.0
mA
mA
mA
0.30
0.30
10
11
5.0
15.0
20.0
15.0
20.0
V
V
Ω
pF
µs
µs
µs
µs
TEST CONDITIONS
I
F
= 10.0 mA
I
F
= 10.0 mA, T
A
= -55
o
C
I
F
= 10.0 mA, T
A
= 100
o
C
V
R
= 2.0 V
I
C
= 1.0 mA, I
F
= 0
I
E
= 100
µA,
I
F
= 0
V
CE
= 20 V, I
F
= 0
V
CE
= 20 V, I
F
= 0, T
A
= 100
o
C
V
CE
= 5.0 V, I
F
= 2.0 mA
V
CE
= 5.0 V, I
F
= 10.0 mA
V
CE
= 5.0 V, I
F
= 10.0 mA, T
A
= -55
o
C
V
CE
= 5.0 V, I
F
= 10.0 mA, T
A
= 100
o
C
V
CE
= 5.0 V, I
F
= 2.0 mA
V
CE
= 5.0 V, I
F
= 10.0 mA
V
CE
= 5.0 V, I
F
= 10.0 mA, T
A
= -55
o
C
V
CE
= 5.0 V, I
F
= 10.0 mA, T
A
= 100
o
C
I
C
= 2.5 mA, I
F
= 20.0 mA
I
C
= 10.0 mA, I
F
= 20.0 mA
V
I-O
= ±1000 VDC
(1)
V
I-O
= 0.0 V, f = 1.0 MHz
(1)
V
CC
= 10.0 V, I
F
= 10.0 mA, R
L
= 100
Ω
Forward Voltage
I
R
V
(BR)CEO
V
(BR)ECO
I
C(OFF)
Reverse Current
Collector-Emitter Breakdown Voltage
(3)
Emitter-Collector Breakdown Voltage
(4)
Collector-Emitter Dark Current
Output Phototransistor
Coupled
On-State Collector Current
HCC240
0.15
2.5
1.0
1.0
I
C(ON)
HCC242
0.40
10.0
4.0
4.0
V
CE(SAT)
R
I-O
C
I-O
t
r
Collector-Emitter Saturation Voltage
HCC240
HCC242
Resistance (Input to Output)
Capacitance (Input to Output)
Output Rise Time
HCC240
HCC242
t
f
Output Fall Time
HCC240
HCC242
V
CC
= 10.0 V, I
F
= 10.0 mA, R
L
= 100
Ω
Optek reserves the right to make changes at any time in order to improve design and to supply the best product possible.
Optek Technology, Inc.
1215 W. Crosby Road
Carrollton, Texas 75006
(972) 323-2200
Fax (972) 323-2396
15-29
