RC73C3B2492FTF

Description
Fixed Resistor, Metal Glaze/thick Film, 2W, 24900ohm, 500V, 1% +/-Tol, 50ppm/Cel, Surface Mount, 2512, CHIP, LEAD FREE
CategoryPassive components    The resistor
File Size389KB,2 Pages
ManufacturerSMEC Inc
Websitehttp://www.smec-inc.com
Environmental Compliance
Download Datasheet Parametric View All

RC73C3B2492FTF Overview

Fixed Resistor, Metal Glaze/thick Film, 2W, 24900ohm, 500V, 1% +/-Tol, 50ppm/Cel, Surface Mount, 2512, CHIP, LEAD FREE

RC73C3B2492FTF Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerSMEC Inc
package instruction, 2512
Reach Compliance Codecompliant
JESD-609 codee3
Manufacturer's serial numberRC73
Installation featuresSURFACE MOUNT
Number of terminals2
Maximum operating temperature175 °C
Minimum operating temperature-55 °C
Package shapeRECTANGULAR PACKAGE
method of packingTR, EMBOSSED
Rated power dissipation(P)2 W
Rated temperature70 °C
resistance24900 Ω
Resistor typeFIXED RESISTOR
size code2512
surface mountYES
technologyMETAL GLAZE/THICK FILM
Temperature Coefficient50 ppm/°C
Terminal surfaceTin (Sn) - with Nickel (Ni) barrier
Terminal shapeWRAPAROUND
Tolerance1%
Operating Voltage500 V
Base Number Matches1
THICK FILM
CHIP RESISTORS
T Y P E
CONSTRUCTION
1.
Ceramic Substrate
2.
Ru0
2
Resistor Film
3.
Over Coating
4.
Termination 1 (AgPd)
5.
Termination 2 (Ni)
6.
Termination 3 (Sn)
R C 7 3
DIMENSIONS
Mark
2Y
2Z/2W
2X/2C/2P
2A/2D/2K
2B/2E
2F/2G
2H/2I
3A
3B
EIA
0201
0402
0603
0805
1206
1210
2010
2512
2512
Power Rating
0.05W
0.063W/0.1W
0.063W/0.1W/0.25W
0.1W/0.125W/0.25W
0.125W/0.25W
0.25W/0.5W
0.5W/1W
1W
2W
L
0.6
±
0.03
1.0
±
0.1
1.6
±
0.15
2.0
±
0.2
3.2
±
0.2
3.2
±
0.2
5.0
±
0.2
6.4
±
0.2
6.4
±
0.2
W
0.3
±
0.03
0.5
±
0.1
0.8
±
0.15
1.25
±
0.2
1.6
±
0.2
2.5
±
0.2
2.5
±
0.2
3.2
±
0.2
3.2
±
0.2
H
0.23
±
0.03
0.35
±
0.1
0.45
±
0.1
0.45
±
0.1
0.55
±
0.1
0.55
±
0.1
0.55
±
0.1
0.55
±
0.1
0.55
±
0.1
D
0.15
±
0.05
0.2
±
0.1
0.3
±
0.2
0.3
±
0.2
0.5
±
0.2
0.5
±
0.2
1.0
±
0.2
1.3
±
0.2
1.3
±
0.2
(Unit: mm)
d
0.2
Max
0.3
Max
0.4
Max
0.42
Max
0.52 Max
0.52 Max
0.8 Max
1.3 Max
1.3 Max
RESISTANCE RANGE
Item
T.C.R. (PPM°/C)
Resistance
Tolerance
Power Rating
T.C.R.
Mark
0.05W
2Y
0.063W
2Z/2X
0.1W
2W/2C/2A
0.125W
2D/2B
0.25W
2E/2F
0.5W
2G/2H
1W
2I/3A
2W
3B
±100, ±
50 A, C
±
200
L
±
1%
F
±
5%
J
10Ω~1MΩ
10Ω~1MΩ
10Ω~1MΩ
10Ω~1MΩ
10Ω~1MΩ
1Ω~5.6MΩ
10Ω~1MΩ
1Ω~5.6MΩ
10Ω~1MΩ
1Ω~100MΩ
10Ω~1MΩ
1Ω~100MΩ
1Ω~10MΩ
1Ω~100MΩ
1Ω~10MΩ
1Ω~100MΩ
1Ω~10MΩ
1Ω~100MΩ
1Ω~10MΩ
1Ω~100MΩ
RATING
Item
Max Working Voltage
Max Over-Load Voltage
Operating Temp. Range
Rating Temp.
Power
Mark
10Ω~1MΩ
10Ω~1MΩ
1Ω~1MΩ
1Ω~100MΩ
1Ω~100MΩ 1Ω~100MΩ
10Ω~1MΩ
10Ω~1MΩ
10Ω~1MΩ
1Ω~100MΩ
1Ω~100MΩ 1Ω~100MΩ
*Main Resistance Value: E-24, E-96 Series (see back)
0.5W
2G/2H
0.05W
2Y
0.063W
2Z/2X
0.1W
2W/2C/2A
0.125W
2D/2B
0.25W
2E/2F
1W
2I/3A
2W
3B
25V
50V
50V
100V
50V
100V
200V
400V
– 55° C to +175° C
70° C
200V
400V
250V
500V
300V
600V
500V
1000V
CHARACTERISTICS
Requirements
Short time Over-Load
Soldering Heat
Temperature Cycling
Moisture Load-Life
Load-Life
Dielectric-Withstanding Voltage
Characteristics
±2.5%
±3%
±1%
±5%
(2Y), (2Z), (2X),
±3%
±5%
(2Y), (2Z), (2X),
±3%
±1%
Text Method
Rated Voltage x 2.5, 5 seconds.
260°C, 10 seconds.
–55°C~155°C, 0.5 hours, 5 cycles
40°C 95% RH Rated Voltage 1000H
Rated Voltage 1000 Hours
Max Working Voltage
DERATING CURVE
100
80
60
40
20
0
–55
20
40
60
80
100
120
140
160
170
180
Ambient Temperature
°C
70°C
175°C
ORDERING INFORMATION
RC 73 A 2B 1001 F T
F
RC 73 L 2B 102 J T
F
*
**
Pb Free
(
Rated Load %
Taping
Resistance Tolerance
Resistance Value
Power Rating
Temperature Coefficient (T.C.)
Chip Type
Thick Film
* L=T.C. for 5% Tol.; A or C=T.C. for 1% Tol.
** 102 = 3 digit for 5% Tol., 1001 = 4 digit for 1% Tol.
Web Site: http://www.smec-inc.com
Return to
Contents Page
e-mail: sales@smec-inc.com
