general purpose 2%, 5% tolerance
thick film chip resistor
EU
features
•
Marking: No marking on 1F, 1H & 1E
sizes, black protective coat.
White, three-digit marking on
1J ~ 3A on black protective coat.
•
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended
for Pb-glass contained in electrode, resistor element
and glass.
•
AEC-Q200 Qualified: 0201 (1H), 0402 (1E), 0603 (1J), 0805
(2A), 1206 (2B), 1210 (2E), 2010 (2H/W2H), 2512 (3A/W3A)
dimensions and construction
c
L
c
(Inch Size Code)
W
Solder
Plating
t
d
Protective
Coating
Resistive Inner
Film
Electrode
Ni
Plating
1F
(01005)
1E
(0402)
1H
(0201)
Type*
.015±.001 .007±.001 .004±.001 .004±.001 .005±.001
(0.4±0.02) (0.2±0.02) (0.10±0.03) (0.11±0.03) (0.13±0.02)
.024±.001 .012±.001 .004±.002 .006±.002 .009±.001
(0.6±0.03) (0.3±0.03) (0.1±0.05) (0.15±0.05) (0.23±0.03)
.039
(1.0
+.004
-.002
+0.1
-0.05
)
+.002
.02±.002 .008±.004 .01
-.004
.014±.002
(0.5±0.05) (0.2±0.1) (0.25
+0.05
) (0.35±0.05)
-0.1
L
Dimensions
inches
(mm)
W
c
d
t
Derating Curve
100
80
60
40
20
0
Ceramic
Substrate
100
1E, 1J, 2A, 2B, 2E, W2H,
W3A, 2H/W2H, 3A/W3A
80
% Rated Power
60
40
20
0
-60 -40
-55
2B
(1206)
2H
(2010)
3A
(2512)
2A
(0805)
1J
(0603)
.063±.008 .031±.004 .012±.004 .012±.004 .018±.004
(1.6±0.2)
(0.8±0.1)
(0.3±0.1) (0.45±0.1)
(0.3±0.1)
.079±.008 .049±.004 .016±.008
(2.0±0.2) (1.25±0.1) (0.4±0.2)
.063±.008
.126±.008
(1.6±0.2)
(3.2±0.2)
.102±.008
(2.6±0.2)
.197±.008 .098±.008
(5.0±0.2)
(2.5±0.2)
.012
(0.3
+.008
-.004
+0.2
-0.1
)
.02±.004
(0.5±0.1)
1F
1E, 1H, 1J, 2A, 2B, 2E, 2H,
3A, W2H, W3A
3A, W2H, W3A
2E
(1210)
W2H
(2010)
.016
(0.4
+.008
-.004
+0.2
-0.1
)
0
20
40
100 120
140
160 180
70
125
155
Ambient Temperature
(°C)
60
80
-20
0
100 120
140 160
125
155
Terminal Part Temperature
(°C)
20
40
60
80
For resistors operated at an ambient
temperature of 70°C or above, a power
rating shall be derated in accordance
with the above derating curve.
For resistors operated at a terminal part
temperature of described for each size or
above, a power rating shall be derated in
accordance with the above derating curve.
Please refer to “Introduction of the derating
curve based on the terminal part temperature”
on the beginning of our catalog before use.
.02±.012
(0.5±0.3)
.026±.006 .024±.004
(0.65±0.15) (0.6±0.1)
.016
(0.4
+.008
-.004
+0.2
)
-0.1
New Part #
ordering information
RK73B
Type
2B
Size
1F
1H
1E
1J
2A
2B
2E
W2H
W3A
2H
3A
* Parentheses indicate EIA package size codes.
T
TD
Packaging
TX: 01005 only: 4mm width - 1mm pitch plastic embossed
TBL: 01005 only: 2mm pitch pressed paper
TA: 0201 only: 1mm pitch pressed paper
TC: 0201 only: 7" 2mm pitch pressed paper
(TC: 10,000 pcs/reel, TCM: 15,000 pcs/reel)
TCD: 0201 only: 10" 2mm pitch pressed paper
TPD: 0402 only: 10" plastic embossed
TPL: 0402 only: 2mm pitch punched paper
TP: 0402, 0603 & 0805: 7" 2mm pitch punched paper
TD: 0603, 0805, 1206 &1210: 7" 4mm pitch punched paper
TDD: 0603, 0805, 1206 &1210: 10" paper tape
TE: 0805, 1206, 1210, 2010 & 2512: 7" plastic embossed
TED: 0805, 1206, 1210, 2010 & 2512: 10" plastic embossed
For further information on packaging, please refer to Appendix A
W3A
(2512)
.248±.008 .122±.008
(6.3±0.2)
(3.1±0.2)
.026±.006
(0.65±0.15)
102
J
Tolerance
G: ±2%
J: ±5%
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
Termination
Material
T: Sn
(1F ~ 3A)
Contact factory
for below options:
L: SnPb
(1E, 1J, 2A, 2B,
2E, 2H, 3A)
G: Au
(1E ~ 2A:
10Ω ~ 1MΩ)
X: Bondable
(1J ~ 2E:
10Ω ~ 1MΩ)
Nominal
Resistance
2 significant
figures + 1
multiplier
“R” indicates
decimal on
value <10Ω
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
11/27/14
13
resistors
RK73B
RK73B
general purpose 2%, 5% tolerance
thick film chip resistor
applications and ratings
Part
Designation
RK73B1F
(01005)
RK73B1H
(0201)
RK73B1E
(0402)
RK73B1J
(0603)
T.C.R.
(x10
-6
/K)
±200
±250
±300
0~+300
±200
±400
±200
±200
±400
±200
±400
±200
±400
±200
±400
±200
±400
±200
1.0W
±400
—
6.2MΩ - 22MΩ
0.75W
0.25W
0.50W
0.33W (0.5W*)
0.125W (0.25W*)
0.10W (0.125W*)
0.05W
0.063W (0.1W*)
0.03W
Power
Rating
@ 70°C
G±2%
E-24
Resistance Range
J±5%
E-24
Maximum
Working
Voltage
Maximum
Overload
Voltage
resistors
100kΩ - 1MΩ
100Ω - 91kΩ
10Ω - 91Ω
1Ω - 9.1Ω
10Ω - 10MΩ
—
1Ω - 10MΩ
1Ω - 10MΩ
—
1Ω - 1MΩ
1.1MΩ - 10MΩ
1Ω - 5.6MΩ
6.2MΩ - 10MΩ
10Ω - 1kΩ
1.1kΩ - 5.6MΩ
—
10Ω - 5.6MΩ
—
10Ω - 5.6MΩ
100kΩ - 1MΩ
100Ω - 91kΩ
10Ω - 91Ω
1Ω - 9.1Ω
10Ω - 10MΩ
1Ω - 9.1Ω
1Ω - 10MΩ
1Ω - 10MΩ
11MΩ - 22MΩ
1Ω - 1MΩ
1.1MΩ - 10MΩ
1Ω - 5.6MΩ
6.2MΩ - 22MΩ
1Ω - 1KΩ
1.1KΩ - 5.6MΩ
200V
6.2MΩ - 10MΩ
1Ω - 5.6MΩ
6.2MΩ - 22MΩ
1Ω - 5.6MΩ
200V
(500V*)
400V
(500V*)
400V
150V
200V
50V
100V
25V
50V
20V
30V
Rated
Operating
Terminal
Temperature
Part
Range
Temperature
-55°C to
+125°C
—
RK73B2B
(1206)
RK73B2E
(1210)
RK73B2A
(0805)
125°C
-55°C to
+155°C
RK73BW3A/3A
(2512)
RK73BW2H/2H
(2010)
Rated ambient temperature: +70°C
Rated voltage =
√Power
rating x resistance value or max. working voltage, whichever is lower
* Please refer to the “Higher Power Ratings” statement in the beginning of the catalog. Also, contact KOA prior to usage and for the max. working voltage
and max. overload voltage.
environmental applications
Parameter
Requirement
∆
R (%+0.1Ω)
Limit
Typical
—
—
Test Method
Performance Characteristics
Resistance
T.C.R.
Overload (Short time)
Resistance to Soldering Heat
Rapid Change of Temperature
Moisture Resistance
Endurance at 70°C
High Temperature Exposure
Within specified tolerance
Within specified T.C.R.
±2%
25°C
+25°C/-55°C and +25°C/+125°C
Rated Voltage x 2.5 for 5 seconds
(2B: Rated Voltage x 2 for 5 seconds)
260°C ± 5°C, 10 seconds ± 1 second
-55°C (30 minutes), +125°C (30 minutes), 100 cycles
40°C ± 2°C, 90%-95% RH, 1000 hours, 1.5 hr ON,
0.5 hr OFF cycle
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
+125°C, 1000 hours: 1F; +155°C, 1000 hours: 1E, 1H,
1J, 2A, 2B, 2E, 2H/W2H, 3A/W3A
12/05/14
±1%: 1F
±0.5%: Another
±0.5%: 1F~W3A
±1%: 1F~W3A (10Ω≤R≤1MΩ) (10Ω≤R≤1MΩ); ±1%: 1F~W3A
±3%: 1F~W3A (R<10Ω, R>1MΩ)
(R<10Ω, R>1MΩ)
±1%: 1F
±0.5%: Another
±2%: 1J, 2A, 2B
±3%: Another
±2%: 1J, 2A, 2B
±3%: Another
±1%
±0.5%: 1F
±0.3%: Another
±0.75%: 1J, 2A, 2B
±1.5%: 1F
±1%: Another
±0.75%: 1J, 2A, 2B
±1%: Another
±0.5%: 1F
±0.3%: Another
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
14
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
